Transition Networks N-GXE-LC-02 Gigabit Ethernet Card shown with a metal bracket and two square LC ports

Transition Networks N-GXE-LC-02 Gigabit Ethernet Card

$ 331.49 $ 331.49
$ 331.49

$ 331.49 / Units
  • Brand
  • Color - Not Specified
  • Depth
  • Weight (Approximate)
  • Height
  • Product Name
  • Marketing Information
  • Brand Name
  • Manufacturer Part Number
  • Network Technology
  • Host Interface
  • Form Factor
  • Keyboard/Keypad Weight (Approximate)
  • Maximum Height Adjustment (Above)
  • Media Type Supported
  • Environmentally Friendly
  • Environmental Compliance
  • Country of Origin
  • Package Contents
  • Limited Warranty
  • Manufacturer
  • Product Type
  • Product Series
  • Product Model
  • Product Condition
  • Device Supported
  • Manufacturer Website Address
Add to cart
Buy now
This product is eligible for 30-day returns. See our return policy for details. Terms and Conditions
Shipping: 1-6 Business Days
Sourced directly through verified US distributors
Contact Us

The N-GXE-xx-02 Series is a Fiber Gigabit Ethernet to PCIe bus adapter that fully complies with all IEEE 802.3z and 1000Base-SX standards. It provides up to 2000 Mbps fullduplex bandwidth capacity to support high-end servers. In addition, with advanced functions like VLAN filtering packet processing, link aggregation, smart load balancing, failover, and Wake-on-LAN, the adapter provides enhanced performance, flexible configuration and secure networking for users in a standard-based environment. An LED indicator on the bracket displays link status, activity and speed.

  • Smart Load Balancing (SLB) and Failover
  • Full Wake-on-LAN Support
  • Link Aggregation Smart Switch
  • Link Aggregation Control Protocol (LACP)
  • Compliant with PCIe Rev 2.1 Interface
  • IEEE 802.1Q VLAN Support
  • Supports IEEE 802.3x and IEEE 802.3z FullDuplex Flow Control
  • Supports full-duplex mode
  • Supports PCIe x1 bus
  • High bandwidth 1000 Mbps network speed (100/1000 Mbps with AutoNegotiation for SFP version)
Brand
Brand Lantronix
Networking & Connectivity
Network Technology 1000Base-SX
Size / Dimensions
Form Factor Plug-in Card
Keyboard/Keypad Weight (Approximate) 8.80 oz
Maximum Height Adjustment (Above) 2.2"
Appearance
Color Not Specified
General Features
Manufacturer Lantronix, Inc
Product Condition New
Misc Ports
Host Interface PCI Express 2.1 x1
Printer/Scanner/Fax Specs
Media Type Supported Optical Fiber
Compliance & Certification
Environmentally Friendly Yes
Brand Lantronix, Inc
UPC/GTIN 648177042111
MPN N-GXE-LC-02
Unit Count 1 Units
Warranty Lifetime
Return Policy This product is eligible for 30-day returns. See our return policy for details.
Transition Networks N-GXE-LC-02 Gigabit Ethernet Card - PCI Express 2.1 x1 - Optical Fiber - 1000Base-SX - Plug-in Card
