MSI Pro PRO A620M-E Gaming Desktop Motherboard - AMD A620 Chipset - Socket AM5 - Micro ATX

Brand

• MSI

Processor Supported

Discrete graphics support

• Yes

USB 2.0 connectors

• 6

Ethernet interface type

• Gigabit Ethernet

USB 3.2 Gen 1 (3.1 Gen 1) connectors

• 6

Number of SATA III connectors

• 4

Total number of SATA connectors

• 4

ATX Power connector (24-pin)

• Yes

Power fan connector

• Yes

CPU fan connector

• Yes

Number of chassis fan connectors

• 1

Chassis intrusion connector

• Yes

Number of COM connectors

• 1

TPM connector

• Yes

RGB LED pin header

• Yes

USB 2.0 ports quantity

• 6

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity

• 6

Ethernet LAN (RJ-45) ports

• 1

PS/2 ports quantity

• 2

VGA (D-Sub) ports quantity

• 1

HDMI ports quantity

• 1

HDMI version

• 2.1

Headphone outputs

• 1

Line-in

• Yes

Microphone in

• Yes

COM ports quantity

• 1

Ethernet LAN

• Yes

LAN controller

• Realtek RTL8111H

Wi-Fi

• No

Motherboard chipset

• AMD A620

Audio chip

• Realtek ALC897

Motherboard form factor

• micro ATX

Motherboard chipset family

• AMD

Cooling type

• Active

Power source type

• ATX

PCI Express x1 slots

• 1

PCI Express x1 (Gen 3.x) slots

• 1

PCI Express x16 slots

• 1

PCI Express x16 (Gen 4.x) slots

• 1

Number of M.2 (M) slots

• 1

Width

• 211 mm

Depth

• 243.8 mm

Cables included

• SATA

Total Processor Supported

• 1

Component for

• PC

ECC сompatibility

• Non-ECC

Supported storage drive interfaces

• M.2, PCI Express, SATA

Supported memory clock speeds

• 6000 MHz

Product colour

• Black

Processor manufacturer

• AMD

Maximum internal memory

• 96 GB

Processor socket

• Socket AM5

Supported storage drive types

• HDD & SSD

Compatible processor series

• AMD Ryzen™ 7

Maximum resolution

• 3840 x 2160 pixels

AMD Opteron series

• 7000

USB connector type

• USB Type-A

Audio output channels

• 7.1 channels

Maximum number of SMP processors

• 1

Supported processor sockets

• Socket AM5

RAID support

• Yes

Supported memory types

• DDR5-SDRAM

Number of memory slots

• 2

RAID levels

• 0, 1, 10

Memory slots type

• DIMM

Number of storage drives supported

• 5

On-board graphics card

• No

Memory channels

• Dual-channel

Chipset Manufacturer

• AMD

Chipset Model

• A620

RAID Supported

• Yes

Onboard Video

• CPU Dependent Video

Number of M.2 Interfaces

• 1

Total Number of USB Ports

• 6

Total Number of Onboard USB Ports

• 6

Number of USB 2.0 Ports

• 2

Number of Onboard USB 2.0 Ports

• 4

Number of USB 3.2 Gen 1 Type-A Ports

• 4

HDMI

• Yes

HDMI Version

Number of Network (RJ-45) Ports

• 1

Gigabit Ethernet

• Yes

VGA

• Yes

Number of SATA Interfaces

• 4

Total Number of PCI Express Slots

• 2

Number of PCI Express x1 Slots

• 1

Number of PCI Express x16 Slots

• 1

Total Number of Expansion Slots

• 2

Form Factor

Processor Socket

• Socket AM5

Memory Technology

Memory Speed Supported

Memory Form Factor

Number of Memory Slots

• 2

Maximum Memory Supported

• 64 GB

RAID Levels

Controller Type

Audio Channels

• 7.1

Country of Origin

• China

Package Contents

Manufacturer

• MSI

Product Type

• Gaming Desktop Motherboard

Product Line

• Pro

Product Model

Manufacturer Website Address

• http://www.msi.com

PCI Express Standard
