View 380 XL TG ARGB Flaming Orange Mid Tower Chassis
The View 380 XL TG ARGB Flaming Orange Mid Tower Chassis is a dual-chamber ATX case with Hidden-Connector Motherboard support, four 120mm Hydraulic Bearing ARGB Lite fans, and space for a 360mm radiator at both the top and motherboard side. It supports up to ten 120mm fans and features a built-in GPU holder, front I/O ports, a recessed bottom compartment, and an angled motherboard side design, offering users enhanced flexibility for their ideal build.
Compatible with Hidden-Connector Motherboards
Created for next-generation motherboards, the View 380 XL TG ARGB Flaming Orange Mid Tower Chassis features a special design that support both standard motherboards and hidden-connector motherboards from ASUS, MSI and GIGABYTE.
Compatible with hidden-connector motherboards:
ASUS BTF Series
MSI PROJECT ZERO Series
GIGABYTE PROJECT STEALTH Series
Dual Chamber Design
The dual chamber design provides more build space, better cable management, and improved airflow for better flexibility.
Tempered Glass Front and Left Panels
The View 380 XL TG ARGB Flaming Orange Mid Tower Chassis is designed for better visibility, featuring tempered glass front and left panels, allowing users to enjoy their system with a stylish touch.
Good Radiator Support
For good cooling support, users can choose to place a 360mm radiator on the top and motherboard side.
Four Hydraulic Bearing 120mm ARGB Lite Fans Pre-installed
The View 380 XL TG ARGB Flaming Orange Mid Tower Chassis comes with three 120mm ARGB Lite Reverse Fan on the motherboard side and one 120mm ARGB Lite Fan at the rear. It's fascinating lighting effects can be controlled by motherboard software from ASUS, GIGABYTE, MSI, and ASRock.
Built-in GPU Holder
The built-in GPU holder prevents graphics card sagging with extra support.
Flexibility to Build Your Ideal PC
The View 380 XL TG ARGB Flaming Orange Mid Tower Chassis offers good expandability. It can support a CPU cooler with a maximum height of 160mm, GPU placement up to 420mm in length, a power supply up to 180mm in length. Optimized for excellent cooling performance, the case comes with three 120mm ARGB Lite Reverse Fan on the motherboard side and one 120mm ARGB Lite Fan at the rear, and up to ten 120mm fans can be installed. For radiator compatibility, it can support up to a 360mm radiator at the top or the motherboard side, giving more options for high-end expansion!
Dimensions
CPU Cooler
Max height 160mm
Motherboard
6.7" x 6.7" (Mini ITX), 9.6" x 9.6" (Micro ATX), 12" x 9.6" (ATX)
VGA
Length limitation 420mm
PSU Support
PSU
Max length 180mm
Fan Capacity
- 120mm
- 140mm
Radiator Capacity
- 120mm
- 140mm
- 240mm
- 280mm
- 360mm
- Supports ATX motherboards to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
- 3 bays for a tailor-made PC configuration
- For a better airflow, mid-tower structure supports up to 10 fan(s) with ample space to store hardware
| Brand | |
|---|---|
| Brand | Thermaltake Technology Co. |
| GPU / Graphics | |
|---|---|
| Maximum GPU Length | 16.54" |
| Power & Battery | |
|---|---|
| Maximum PSU Length | 7.09" |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 3 |
| Front USB | Yes |
| USB Port Details | 1 x USB 3.2 Gen 2 Type C |
| Audio Ports | |
|---|---|
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Mid-tower |
| Appearance | |
|---|---|
| Color | Flaming Orange |
| Window Panel | Yes |
| Window Panel Location | Left Side |
| General Features | |
|---|---|
| Motherboard Supported | EATX |
| Cooler Type | Fan/Liquid Cooler |
| Installed Fan Size | 4.72" |
| Installed Fan Size Details | 4 x 120mm |
| Fan Size Supported | 5.51" |
| Maximum CPU Cooler Height | 6.30" |
| Manufacturer | Thermaltake Technology Co., Ltd |
| Number of Fans Supported | 10 |
| Number of Fans Installed | 4 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 8 |
| Drive Bays | |
|---|---|
| Number of Total Expansion Bays | 3 |
| Number of Internal 2.5" Bays | 2 |
| Number of Internal 3.5" Bays | 1 |
| Brand | Thermaltake Technology Co., Ltd |
| UPC/GTIN | 840480308810 |
| MPN | CA-11E-00MRWN-00 |
| Unit Count | 1 Units |
| Warranty | 3 Year |
