With its minimalist design and sleek exterior, the CJ Series fuses itself within any environment. Living room, home office, or corporate cubicle, it easily blends into anywhere with its compact size.
Placement in both Vertical or Horizontal stance.
80mm PWM Cooling Fan
Superior Performance
The CJ Series is just 8L in volume, but it accommodates a slim ODD, 3.5"/2.5" HDD, 2.5" HDD, four low-profile PCI cards, and even one card reader! It offers exceptional flexibility and scalability for enhanced multi-function applications!
Highly Expandable
Supports USB 3.0, USB 2.0, Type-C and card reader ports at the front for multiple device connections.
Advanced Thermal Solution
Hosts an 80mm case fan with plenty of ventilation providing exceptional cooling performance.
Detachable Drive Cage
The removable drive cage features a slim ODD, 3.5" and 2.5" HDD tool-free bays for easy installation.
Quick Top Cover Eject Clip
A switch releases the top cover for faster system assembly or maintenance.
Supports Micro-ATX Motherboard
Efficiently utilizes its compact size to support Micro-ATX form factor motherboard, providing flexibility for integrators.
Standard Flex ATX 265W Power Supply
Includes a built-in a Flex ATX 265W power supply. Its slim size with standby low power consumption and fan speed control for a better computing experience.
- Mini ITX motherboard builds a perfect symmetry of hardware components required in media server or NAS box
- 3 bays for a tailor-made PC configuration
- Handy configuration ultra small offers quick upgrades and saves time and maintenance cost
| Brand | |
|---|---|
| Brand | In Win Development |
| Power & Battery | |
|---|---|
| Number of Power Supplies Supp | 1 |
| Number of Power Supplies Inst | 1 |
| Power Supply Wattage | 265 W |
| Power Supply Installed | Yes |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 4 |
| Audio Ports | |
|---|---|
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Size / Dimensions | |
|---|---|
| Form Factor | Ultra Small |
| General Features | |
|---|---|
| Motherboard Supported | Mini ITX |
| Cooler Type | Fan Cooler |
| Installed Fan Size | 3.15" |
| Manufacturer | In Win Development, Inc |
| Number of Fans Supported | 1 |
| Number of Fans Installed | 1 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 4 |
| Drive Bays | |
|---|---|
| Number of Internal 2.5"/3.5" | 1 |
| Number of Total Expansion Bays | 3 |
| Number of Internal 2.5" Bays | 1 |
| Number of External 5.25" Bays | 1 |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Packaging & Origin | |
|---|---|
| Package Type | Retail |
