The PNM-C16083RVQ is a unique, high-resolution multi-sensor multi-directional camera capable of providing 4MP on each of its' 4 sensors. Each sensor can be manually adjusted for pan along the track, tilt & rotation, along with motorized zoom, & focus control. The powerful AI capabilities enhance the license-free video analytics to reduce false alarms and provide quick and accurate forensic search with a compatible VMS.
- 4MP x 4ch multi-directional camera, using one IP address
- 30fps@4MP (H.265, H.264)
- 3.3~5.7mm (FoV H: 109°~56°, V: 55°~31°) motorized varifocal lens
- Integrated IR that rotates with camera head, IR viewable length WiseIR 15m (49.21ft)
- H.265, H.264, MJPEG codec, Multi streaming
- 120dB WDR
- USB port for easy installation
- Analytics events based on AI engine: Object detection [Person/Vehicle (Car/Bus/Truck/Motorcycle/Bicycle)], IVA (Virtual line/Area, Enter/Exit, Loitering, direction, intrusion), Appear/Disappear
- WiseNR ?(using AI engine), WiseStream?(Based on AI engine)
- I/O Box compatibility for audio & alarm I/O
- TPM with FIPS 140-2 level 2
- micro SD card 512GB x2
- Operating Temperature: -40°C~+55°C(-40°F~+131°F)
- PoE+ powered
- Hard-coated dome bubble
- IP66, IK10, NEMA4X
- Easy Gangbox mounting installation
- Network camera - Helps achieve high-quality video results
- Up to 2592 x 1520 resolution for surveillance in real-time
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- 5.70 mm maximum focal length provides incredible detail and how effective is your network camera
- f/1.5 maximum aperture for reliable, detailed, and sharp output with added dependability
- 1.7x optical zoom for bringing the subject closer for maximum surveillance efficiency
- Provides night vision of objects at a distance of up to 49.21 ft
- Infrared night vision type efficiently detects infrared waves that are invisible to the naked eye
- Fixed camera iris is ideal for indoor video surveillance where light levels are constant and unchanged
- Varifocal lens type to ensure maximum surveillance dependability and optimal performance
| Brand | |
|---|---|
| Brand | Hanwha Group |
| Storage | |
|---|---|
| Storage Type | Memory Card |
| Screen / Display | |
|---|---|
| Color Supported | Color |
| Power & Battery | |
|---|---|
| Maximum Power Consumption | 25.50 W |
| Power Source Type | PoE+ |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| Protocols | ONVIF |
| USB Ports | |
|---|---|
| USB | Yes |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Camera / Webcam | |
|---|---|
| Optical Zoom | 1.7x |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Type | Infrared |
| Effective Camera Resolution | 4 Megapixel |
| Image Sensor Type | CMOS |
| Minimum Focal Length | 3.30 mm |
| Maximum Focal Length | 5.70 mm |
| Minimum Aperture | f/1.9 |
| Maximum Aperture | f/1.5 |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 2 Second |
| Lens Type | Varifocal |
| Night Vision Distance | 49.21 ft |
| Maximum Frame Rate | 30 fps |
| Image Sensor Size | 1/2.8" |
| Camera Iris | Fixed |
| Field of View | H: 100°(Wide)~53°(Tele) V: 54°(Wide)~30°(Tele) D: 125°(Wide)~61°(Tele) |
| Size / Dimensions | |
|---|---|
| Form Factor | Dome |
| Diameter | 9.8" |
| Mount Type | Hanging Mount |
| Appearance | |
|---|---|
| Color | White |
| General Features | |
|---|---|
| Remote Management | Yes |
| Indoor/Outdoor | Outdoor |
| Video Formats | H.265M |
| Number of Sensors | 4 |
| Manufacturer | Hanwha Group |
| Maximum Video Resolution (Content) | 2592 x 1520 |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 131°F (55°C) |
| Minimum Operating Temperature | -40°F (-40°C) |
| Maximum Operating Humidity (Non-condensing) | 95% |
| Ingress Protection Rating | IP66 |
| Impact Protection Rating | IK10 |
| Brand | Hanwha Group |
| GTIN | 8801089225276 |
| MPN | PNM-C16083RVQ |
| Unit Count | 1 Units |
| Return Policy | This product is eligible for 30-day returns. See our return policy for details. |
