Natural Elegance,Optimal Airflow
The ProArt PA401 Wood Edition showcases a wooden front panel that creates a distinctive, elegant style while promoting sustainability. The wood used is certified by the Forest Stewardship Council®(FSC®), and is finished using a six-stage process. The case also boasts optimal built-in cooling, with two 160mm front fans and one 120mm rear fan, along with an integrated fan hub, enabling optimal airflow.
Open grille for maximum air intake
160 x 32mm front ring fan blades for enhanced thermal performance
Durable, FSC® certified ash wood
COOLING
Exceptional Cooling Performance
The PA401 Wood Edition features a front grille with 33% porosity to maximize airflow and ventilation. Meanwhile, built-in dual 160mm front fans efficiently deliver up to 138cfm of airflow to graphics cards and CPU coolers, and the outer ring connecting these fan blades helps reduce initial vibration. The front fans and the 120mm rear fan with PWM control yield optimal airflow, low noise, low vibration and high reliability.
Fans with ring blade design provide efficient cooling
18mm open-grille design with 33% porosity
Rear fan 120 x 28mm
Front fan 160 x 32mm
Natural Elegance
Crafted Wood
Ash wood, an uncommon choice for this style of case, has been selected for its durability. The special six-stage production process used to create the front panel begins with thermowood treatment, protecting the wood from insects, humidity and heat. The panel material is then shaped to exact specification. Finally, a two-step coating elevates the unique Ash grain with a glossy finish.
The ash wood used for ProArt PA401 Wood Edition is sustainably sourced and is certified by the FSC®.
WOODEN FRONT PANEL
Seamlessly blends tech with a natural aesthetic
Connectivity
Flexible, Fast I/O
Connectivity options are easily accessible via the front I/O panel, including one two-section PWM control, one 20Gbps USB Type-C® port, two USB-A 3.0 ports, HD audio and a Power and Reset button lock.
Premium Fan Speed Control
With integrated PWM control, fan speed adjusts automatically, making it easy to switch between normal and working scenarios and intensive scenarios.
20Gbps USB Type-C®
The PA401 Wood Edition incorporates one 20Gbps USB Type-C port for current and future devices and connectivity with compatible motherboards.
Power and Reset Button Lock
This lock prevents the user from accidentally pressing the Power and Reset buttons.
Design
Builder-Friendly Installation
The ProArt PA401 Wood Edition optimizes the PC building experience, offering better functionality with user-focused features.
The left side panel can be secured via a physical latch to helpprevent intrusion
One-stop PWM fan hub conveniently controlssystem fans
Tool-free 3.5" hard drive installation enables flexibility
Rear bracket detaches from case so that a power supply can slide in for easier installation
Rear cable clips help ensure clean cable management
Compatibility
Compact Form, Ample Interior
The ProArt PA401 Wood Edition features two pre-installed 160mm front fans and accommodates both horizontal and vertical graphics card mounting.
Graphics Card Support
Support 2-way Graphics Card Installation
- Supports ATX motherboards to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
- 4 bays for a tailor-made PC configuration
- The mid-tower structure offers a better airflow and ample space to store hardware
| Brand | |
|---|---|
| Brand | ASUS Computer International |
| GPU / Graphics | |
|---|---|
| Maximum GPU Length | 12.40" |
| Power & Battery | |
|---|---|
| Maximum PSU Length | 6.69" |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 3 |
| Front USB | Yes |
| USB Port Details | 1 x USB 3.2 Gen 2x2 Type C |
| Audio Ports | |
|---|---|
| Headphone/Microphone Combo Po | Yes |
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Audio | |
|---|---|
| Microphone | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Mid-tower |
| Appearance | |
|---|---|
| Window Panel | Yes |
| Window Panel Location | Side Panel |
| General Features | |
|---|---|
| Motherboard Supported | ATX |
| Cooler Type | Fan Cooler |
| Installed Fan Size | 6.30" |
| Installed Fan Size Details | 2 x 160mm |
| Fan Size Supported | 6.30" |
| Maximum CPU Cooler Height | 6.30" |
| Manufacturer | ASUS Computer International |
| Number of Fans Supported | 4 |
| Number of Fans Installed | 3 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 7 |
| Drive Bays | |
|---|---|
| Number of Internal 2.5"/3.5" | 2 |
| Number of Total Expansion Bays | 4 |
| Number of Internal 2.5" Bays | 2 |
