Maximum Quietness, Minimum Vibration
Even at low speeds the operating sound of the new ARCTIC motor is barely noticeable. Due to a sinus-magnetizing the new motor only creates about 5 % of the vibration from commutation of a regular DC-motor without filter.
Perfect Case Fan Regulation with PWM
The PWM function allows the motherboard to run the fan precisely at its necessary speed. This guarantees the required cooling and minimizes the noise level.
PWM Sharing Technology (PST) Lowers Noise
If you want to improve the cooling efficiency of your computer you get several case fans working in parallel (since it takes ten fans to double the noise level). But what does it help if they don't work together? The PST assures that all of your fans listen to one control signal. E.g. you share the CPU Cooler's PWM signal and assure that your case fans stand down at low load and spin up whenever necessary.
Innovative Design Enables Quiet and Efficient Ventilation
The innovative design of the fan blades improves the airflow and facilitates a highly efficient ventilation. The impeller was designed with a focus on minimising the noise level yet delivering the desired airflow and pressure.
Two Way Installation
- Blow warm air out of the case
- Draw cool air into your case
Long Service Life
The Fluid Dynamic Bearing comes with an oil capsule that avoids lubricant leakage. Thus this bearing is as quiet as a sleeve bearing but comes with a significantly higher service life.
Quality You Can Rely On
To ensure the longevity of our products, we carry out long-term tests under different, sometimes very adverse conditions. In this way, we learn how to improve our products for our customers. In addition, the excellent results of long-term testing give us the assurance that our products are not only outstanding in terms of quality but also durability. It's a certainty that we are happy to pass on to our customers, which is why we give a 6-year manufacturer's guarantee on the F12 PWM PST.
- Well designed blades and shroud let the air flow over a greater area to enable effective cooling
- Fluid Dynamic Bearing fan bearing type for maximum cooling/heating efficiency with added dependability
- The competent 4.72" fan(s) is specially designed for standard cases
| Brand | |
|---|---|
| Brand | Arctic Cooling |
| Power & Battery | |
|---|---|
| Rated Current | 120 mA |
| Maximum Power Consumption | 1.44 W |
| Size / Dimensions | |
|---|---|
| Maximum Fan Diameter | 4.72" |
| Fan Width | 4.72" |
| Fan Height | 0.98" |
| General Features | |
|---|---|
| Manufacturer | Arctic Cooling |
| Fan Bearing Type | Fluid Dynamic Bearing |
| Maximum Air Pressure | 1mmH2O |
| Fan Speed (Max) | 1350 rpm |
| Fan Speed (Min) | 230 rpm |
| Number of Fans | 1 |
| Maximum Airflow | 53 CFM |
| Cables | |
|---|---|
| Connectors | 4-Pin Connector + 4-Pin Socket |
| Compliance & Certification | |
|---|---|
| Noise Levels (A-Weighted) | 22.5 dB(A) |
