- Compact in size and offers highly efficient solution
- Prevent critical data loss by staying powered during a blackout with up to 325 W load capacity
- 500 VA load capacity provides sufficient backup during power failures
- Replaceable battery for maximum feasibility and better usability
- 120 V AC input voltage for optimal performance with maximum usability
- 120 V AC output voltage for maximum dependability and added productivity
- DIN Rail form factor helps mounting standby ups significantly faster and easier with added dependability
| Brand | |
|---|---|
| Brand | Schneider Electric SA |
| Power & Battery | |
|---|---|
| Replaceable Battery | Yes |
| Input Frequency | 60 Hz |
| Surge Suppression | Yes |
| EPO Port | Yes |
| Input Voltage Range | 75 V AC - 154 V AC |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Load Capacity (Watt) | 325 W |
| Load Capacity (VA) | 500 VA |
| Output Frequency | 63 Hz |
| Surge Energy Rating | 540 J |
| Networking & Connectivity | |
|---|---|
| Network Management | DB-9 RS-232 |
| Size / Dimensions | |
|---|---|
| Form Factor | Panel Mount |
| General Features | |
|---|---|
| Manufacturer | Schneider Electric SA |
| Misc Ports | |
|---|---|
| Serial Port | Yes |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Operating Humidity | 0% - 95% |
| Sound Emission (A-Weighted) | 55 dB(A) |
| Brand | Schneider Electric SA |
| UPC/GTIN | 731304289982 |
| MPN | SUA500PDR |
| Unit Count | 1 Units |
| Warranty | 2 Year |
| Return Policy | This product is eligible for 30-day returns subject to a restocking fee. See our return policy for details. |
