NVIDIA Blackwell Architecture
The Ultimate Platform for Gamers and Creators
Fifth-Gen Tensor Cores
Max AI performance with FP4 and DLSS 4
New Streaming Multiprocessors
Optimized for neural shaders
Fourth-Gen Ray Tracing Cores
Built for Mega Geometry
AI-Enhanced Graphics and Performance
NVIDIA DLSS 4 with Multi Frame Generation
Game-Winning Responsiveness
NVIDIA Reflex 2 with Frame Warp
True-to-Life Graphics
Full ray tracing with neural rendering
Digital Humans and AI Assistants
NVIDIA ACE
Accelerate Your Creativity
NVIDIA Studio creator tools and technology
Enhance Any Video with AI
NVIDIA Broadcast and ninth-gen NVIDIA Encoder
Performance and Reliability
NVIDIA app with Game Ready and Studio Drivers
The Ultimate Gaming Display Technologies
NVIDIA G-SYNC
WINDFORCE COOLING SYSTEM
The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large copper plate, 3D active fans, and screen cooling.
- Powered by the NVIDIA Blackwell architecture and DLSS 4
- Powered by GeForce RTX™ 5070
- Integrated with 12GB GDDR7 192bit memory interface
- WINDFORCE cooling system
- Hawk fan
- Server-grade Thermal conductive gel
- NVIDIA SFF-ready
- RGB Lighting
- Reinforced structure
| Brand | |
|---|---|
| Brand | GIGABYTE Technology |
| GPU / Graphics | |
|---|---|
| Graphics Card | NVIDIA |
| GPU Clock | 2.59 GHz |
| CUDA Cores | 6144 |
| Bus Width | 192 bit |
| API Supported | OpenGL 4.6 |
| Number of Monitors Supported | 4 |
| Memory / RAM | |
|---|---|
| Standard Memory | 12 GB |
| Memory Technology | GDDR7 |
| Memory Clock Speed | 28 GHz |
| Screen / Display | |
|---|---|
| Maximum Digital Display Resol | 7680 x 4320 |
| Power & Battery | |
|---|---|
| Power Supply Wattage | 750 W |
| Power Connector | 2x 8-pin |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Outputs | 1 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 3 |
| Size / Dimensions | |
|---|---|
| Form Factor | Plug-in Card |
| Slot Space Required | Dual |
| General Features | |
|---|---|
| Chipset Manufacturer | NVIDIA |
| Chipset Model | RTX 5070 |
| Chipset Line | GeForce |
| Chipset Series | RTX |
| AI-powered | Yes |
| Cooler Type | Active Cooler |
| Manufacturer | GIGABYTE Technology, Inc |
| Misc Ports | |
|---|---|
| Host Interface | PCI Express 5.0 |
