Reducing false alarm based on deep learning technology
Wisenet AI cameras using AI algorithms filter out irrelevant movements caused by environmental changes such as waving trees, shadows, or animals. While conventional cameras detect motion based on its pixels and generate events even if users want to ignore, Deep Learning-based Wisenet AI cameras generate event alarm only for people and vehicles, reducing false alarms for more efficient operation.
Attribute, BestShot for the forensic search
Metadata including attribute (people : age, gender, colors of top/bottom clothes, wearing glasses, Vehicle : types, colors) is sent to the backend server and used to extract information on specific situations, significantly reducing the time to search the entire video. And Wisenet P series AI cameras are equipped with the BestShot feature for re-identification which ensures that only the most suitable images of classified objects are sent to the backend server.
Wisenet P seires AI cameras can also quickly and accurately detect the objects with or without face mask and immediately sends out alert.
VMS Integration for forensic search applications
Wisenet P series AI cameras offers integration of video management system from Milestone, Genetec using Hanwha Techwin's AI Plug-ins and Wisenet WAVE. These Plug-ins provide improved AI search on Milestone and Genetec's video management system.
Free AI powered COVID-19 Solutions
Wisenet P series AI cameras supports free AI based COVID-19 Solutions including the Occupancy Monitoring Application, Face Mask Detection, and Social Distancing Detection.
- Max. 2MP resolution, Up to 120fps
- 0.007Lux@F1.3, 1/30sec. (Color), 0Lux (B/W, IR LED on)
- Day & Night (ICR), WDR (120dB), WiseNR? (Using AI engine)
- H.265, H.264, MJPEG, WiseStream?, WiseStream? (Using AI engine)
- Video Analytics based on AI - Object detection and classification (Person, Face, Vehicle, License Plate) - Face mask detection, Social distancing detection - Attribute, BestShot
- Compatible with Wisenet Retail Insight v2.0 for Business Intelligence - Age/gender based People counting - Heatmap, Queue management
- TPM with FIPS 140-2 level2, Secure boot, Verify firmware forgery
- System requirements - SSM v2.10.8 or later, Genetec plugin v1.0 or later, Milestone plugin v1.0.2 or later, NVR model (XRN-6410DB4/B4, XRN-3210B4)
- Hard-coated dome bubble, IP52, IK10
| Brand | |
|---|---|
| Brand | Hanwha Group |
| Storage | |
|---|---|
| Storage Type | Memory Card |
| Screen / Display | |
|---|---|
| Color Supported | Color |
| Power & Battery | |
|---|---|
| Input Voltage | 12 V DC |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Camera / Webcam | |
|---|---|
| Optical Zoom | 2.1x |
| HD Recording | Yes |
| Night Vision | Yes |
| Lens Included | Yes |
| Effective Camera Resolution | 2 Megapixel |
| Maximum Video Resolution | 1920 x 1080 |
| Image Sensor Type | CMOS |
| Minimum Focal Length | 4.38 mm |
| Maximum Focal Length | 9.33 mm |
| Minimum Aperture | f/1.3 |
| Maximum Aperture | f/2.15 |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 1/5 Second |
| Lens Type | Varifocal |
| Recording Formats | HD |
| Night Vision Distance | 131.23 ft |
| Maximum Frame Rate | 120 fps |
| Field of View | H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele) |
| Size / Dimensions | |
|---|---|
| Form Factor | Dome |
| Diameter | 8.1" |
| General Features | |
|---|---|
| Remote Management | Yes |
| Indoor/Outdoor | Indoor/Outdoor |
| Video Formats | MJPEG |
| Manufacturer | Hanwha Group |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 122°F (50°C) |
| Minimum Operating Temperature | -13°F (-25°C) |
| Maximum Operating Humidity | 90% |
| Ingress Protection Rating | IP52 |
| Impact Protection Rating | IK10 |
