Protects Mission-Critical Rack-Mounted Equipment
- Provides fully regulated sine wave AC output for servers, network storage devices and telecom hardware
- Audible alarm signals loss of utility power, overload and low battery
- 6 NEMA 5-15R outlets
- 10-ft. (3.05 m) power cord with 120V NEMA 5-15P input
- 450-joule surge suppression rating
- Supports half load up to 14 min. and full load up to 4 min.
- Internal batteries designed for hot-swap field replacement
- 2 load banks, each with one outlet controllable remotely to reboot equipment or shed nonessential loads
- Maintains 120V nominal output over input range of 83V-147V without using battery power
- Removes electromagnetic and radio frequency interference that can disrupt or damage equipment's performance
- 99% line mode efficiency saves money and energy and protects the environment
- Compatible with Tripp Lite UPS management cards, such as WEBCARDLX
- USB and DB9 ports enable data-saving unattended shutdown when used with Tripp Lite's PowerAlert software, available via FREE download from www.tripplite.com/poweralert
- EPO port supports emergency shutdown in large facilities
- Hardware included for mounting in 1U of EIA-standard 19 in. 2- or 4-post rack
- Optional 4POSTRAILKIT1U accessory available for extra support in 4-post installations
- Compatible with vertical mount cabinets
- Complies with Federal Trade Agreements Act (TAA) for GSA Schedule purchases
- 14 min. runtime at half load; 4 min. at full load
- 2-year limited warranty, $250,000 Ultimate Lifetime Insurance
- 99% efficiency rating saves energy and operating cost
- Network power management and control capability
- 6 NEMA 5-15R outlets-2 switchable via network interface
- Corrects under- and overvoltages from 83V to 147V
| Brand | |
|---|---|
| Brand | Eaton Corporation |
| Power & Battery | |
|---|---|
| Emergency Power OFF | Yes |
| Battery Management | User replaceable |
| Receptacle Detail | 6 x NEMA 5-15R |
| Receptacle Type | NEMA 5-15R |
| Plug/Connector Type | NEMA 5-15P |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Input Current | 9 A |
| Load Capacity (Watt) | 800 W |
| Load Capacity (VA) | 1000 VA |
| Backup/Run Time (Full Load) | 4 Minute |
| Backup/Run Time (Half Load) | 14 Minute |
| Waveform Type | Sine Wave |
| Surge Energy Rating | 450 J |
| USB Ports | |
|---|---|
| USB | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack/Tower |
| Rack Height | 1U |
| General Features | |
|---|---|
| Hot Swappable | Yes |
| Alarm | Power Failure |
| Protection Type | EMI / RFI |
| Manufacturer | Eaton Corporation |
| Misc Ports | |
|---|---|
| Serial Port | Yes |
| Cables | |
|---|---|
| Cord Length | 10 ft |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| TAA Compliant | Yes |
| Environmentally Friendly | Yes |
| Miscellaneous | |
|---|---|
| Product Name | SmartPro SM1000RM1UTAA 1000VA Tower/Rack Mountable UPS |
