The N-GXE-xx-02 Series is a Fiber Gigabit Ethernet to PCIe bus adapter that fully complies with all IEEE 802.3z and 1000Base-SX standards. It provides up to 2000 Mbps fullduplex bandwidth capacity to support high-end servers. In addition, with advanced functions like VLAN filtering packet processing, link aggregation, smart load balancing, failover, and Wake-on-LAN, the adapter provides enhanced performance, flexible configuration and secure networking for users in a standard-based environment. An LED indicator on the bracket displays link status, activity and speed.
- Full Wake-on-LAN Support
- Link Aggregation Smart Switch
- Smart Load Balancing (SLB) and Failover
- Link Aggregation Control Protocol (LACP)
- Compliant with PCIe Rev 2.1 Interface
- IEEE 802.1Q VLAN Support
- Supports full-duplex mode
- Supports IEEE 802.3x and IEEE 802.3z FullDuplex Flow Control
- High bandwidth 1000 Mbps network speed (100/1000 Mbps with AutoNegotiation for SFP version)
- Supports PCIe x1 bus
| Brand | |
|---|---|
| Brand | Transition Networks |
| Networking & Connectivity | |
|---|---|
| Network Technology | 1000Base-SX |
| Size / Dimensions | |
|---|---|
| Form Factor | Plug-in Card |
| General Features | |
|---|---|
| Manufacturer | Lantronix, Inc |
| Misc Ports | |
|---|---|
| Host Interface | PCI Express 2.1 x1 |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Optical Fiber |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Miscellaneous | |
|---|---|
| Product Name | N-GXE-LC-02 Gigabit Ethernet Card |
