Transition Networks M/E-TX-FX-01(SM) Transceiver/Media Converter

$ 169.99 $ 169.99
$ 169.99

$ 169.99 / Units
  • Brand
  • Depth
  • Weight (Approximate)
  • Height
  • Product Name
  • Number of Network (RJ-45) Por
  • Marketing Information
  • Brand Name
  • Manufacturer Part Number
  • Width
  • Network Technology
  • Network (RJ-45)
  • Fiber Mode Supported
  • Total Number of Ports
  • Fiber Optic Cable Wavelength
  • Number of SC Ports
  • Form Factor
  • Maximum Data Transfer Rate
  • Ethernet Technology
  • Media Type Supported
  • Input Voltage
  • Maximum Distance Supported
  • TAA Compliant
  • Environmentally Friendly
  • Environmental Compliance
  • Certifications & Standards
  • NDAA Compliant
  • Package Contents
  • Limited Warranty
  • Additional Information
  • Manufacturer
  • Product Type
  • Product Series
  • Product Model
  • Application/Usage
  • Manufacturer Website Address
  • Power Source
  • Power Consumption
Add to cart
Buy now
Add to wishlist
This product is eligible for 30-day returns. See our return policy for details. Terms and Conditions
Shipping: 1-6 Business Days
Contact Us
Documents
Manufacturer-Brochure PDF User-Manual PDF

Mini Fast Ethernet Media Converter

100Base-TX to 100Base-FX

The M/E-TX Series is a Fast Ethernet stand-alone Mini media converter that provides cost effective media conversion between 100Base-TX ports and 100Base-FX ports. With its fixed configuration, deployments are just plug-and-play, and its small size makes it ideal for locations where space is limited. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.

  • Fiber integration used in pairs or as a single unit, this mini media converter will ease the integration of fiber optic cabling into copper-rich fast Ethernet environments
  • Extend Network Distance as fiber supports the transmission of Fast Ethernet data over much longer distances than possible twisted pair
  • Low-Latency Layer 1 Design, this mini converter will retransmit Fast Ethernet signals without any store-and-forward packet inspection delays found in other Layer 2 devices
  • Small Size is ideal for conversion locations where available space is limited - 65% smaller than standard media converter
  • Unit and port LEDs allow for quick status information
  • Auto-Negotiation
  • Auto-MDI/MDIX
Brand
Brand Lantronix
Power & Battery
Input Voltage 12 V DC
Power Source AC/DC
Power Consumption 2.60 W
Networking & Connectivity
Network Technology 100Base-TX
Ethernet Port
Number of Network (RJ-45) Por 1
Network (RJ-45) Yes
Size / Dimensions
Form Factor Standalone
General Features
Maximum Data Transfer Rate 100 Mbit/s
Maximum Distance Supported 20 km
Manufacturer Lantronix, Inc
Misc Ports
Total Number of Ports 2
Number of SC Ports 1
Printer/Scanner/Fax Specs
Media Type Supported Twisted Pair
Cables
Fiber Mode Supported Single-mode
Fiber Optic Cable Wavelength 1310 nm
Compliance & Certification
TAA Compliant Yes
Environmentally Friendly Yes
NDAA Compliant Yes
