Long-Distance PtMP & PtP Wi-Fi Transmission, Perfect for Multiple Scenarios
Omada Professional Outdoor Wireless Bridge Solution
Up to 3.1mi (5km) Distance
Ideal for setting up networks in remote locations.
Up to 70° Beamwidth for Wider Deployment
One central AP covers more distributed APs and cameras, eliminating the need for multiple central APs.
Three Ports for More Devices
Connect more cameras and devices without an extra switch.
IP65 Weatherproof for Outdoor Use
Durable performance with IP65 rating and operating range of -40°F to 158°F (-40°C to 70°C).
Standalone or Omada SDN Mode
Flexible dual modes for batch deployment and remote management via the Omada app or Web UI.
Point-to-Point (PtP) Network Expansion or Remote Camera Monitoring | Outdoor PtP (Point-to-Point) Wi-Fi Connection | Extend Wi-Fi to Additional Buildings
Extend your home network or Wi-Fi to your shop, barn, garage, farm, storehouse, guesthouse, or RV.
Extend Wi-Fi to Additional Offices
Provide 550Mbps bandwidth within a 328ft (100m) range using the EAP215-Bridge KIT or EAP211-Bridge KIT.
Elevator PtP Wi-Fi for Surveillance
Record real-time video to an NVR with virtually no hardwiring required
Point-to-Multipoint (PtMP) Connections with Higher Beamwidth for Distributed Cameras | Outdoor PtMP (Point-to-Multipoint) Wi-Fi for Surveillance | Parking Lots
Remotely connect cameras to reduce crime and accidents
Farms / Orchards
Remotely connect cameras to protect your property
Construction Sites
Rapidly deploy wireless networks to remotely monitor construction progress in real time or manage logistics.
- 802.11ac for up to 867 Mbps on the 5 GHz wireless data rate.
- Ideal for long-range wireless transmission up to 1 km.
- Auto-pairing and agile LEDs for efficient deployment.
- 3� Gigabit Ethernet ports for more high-speed IP camera connections.
- Supports Omada SDN for remote and centralized management.
- IP65 weatherproof enclosure and 6kV lightning protection ensure all-weather suitability.
- Supports Passive PoE for flexible deployment (adapter included).
| Brand | |
|---|---|
| Brand | TP-LINK Technologies Co. |
| Power & Battery | |
|---|---|
| Power Consumption | 11.50 W |
| Networking & Connectivity | |
|---|---|
| Wi-Fi Generation | Wi-Fi 5 |
| Beamforming Technology | Yes |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Total Number of Antennas | 2 |
| Number of Internal Antennas | 2 |
| Wireless Transmission Speed | 867 Mbit/s |
| Frequency Band | 5 GHz |
| Network Band | Single Band |
| Communication Protocols | RADIUS |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 3 |
| Number of Network (RJ-45) Ports | 3 |
| PoE PD Port | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Pole-mountable |
| Antenna Form Factor | Internal |
| Security | |
|---|---|
| Data Encryption | Yes |
| Encryption Standard | WPA2-ENT |
| General Features | |
|---|---|
| Indoor/Outdoor | Indoor/Outdoor |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Compliance & Certification | |
|---|---|
| Ingress Protection (IP) Rating | IP65 |
