High compatibility with no compromise
Unlike most SFF Mini-ITX chassis on the market, SG14 is capable of fitting a 3 slot full length graphics cards on the left side and up to 240mm radiators on the right side.
Exceptional usability & upgradability
Modular design allows for removal of 4 panels which eases the build process and ease of upgradability at a later date.
2-way placement
SG14's chassis supports 3 x 2.5
Cooling capabilities
AIR Cooling
Thoughtful design down to the details
- 1 GPU holder
- 2. M.2 cutout
- 3. CPU cooler cutout
- 4. ATX PSU support;
- Supports 3 slot full length graphics cards with adjustable graphics card holder
- Compatible with Mini-DTX / Mini-ITX motherboard & ATX PSU
- Supports up to 240mm radiators
- Modular design with 4 removable panels (top, left, right, bottom)
- Different configurations support various storage components for 5.25" , 3.5" and 2.5"
- Front I/O port includes: USB 3.0 x 2, USB 2.0 x 1, combo audio x 1
- Compatible with SFF-Ready Enthusiast GeForce Cards
| Brand | |
|---|---|
| Brand | SilverStone Technology |
| GPU / Graphics | |
|---|---|
| Maximum GPU Length | 12.99" |
| Power & Battery | |
|---|---|
| Maximum PSU Length | 5.91" |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 3 |
| Front USB | Yes |
| USB Port Details | 1 x USB 2.0 |
| Audio Ports | |
|---|---|
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| General Features | |
|---|---|
| Motherboard Supported | Mini ITX |
| Cooler Type | Fan/Liquid Cooler |
| Installed Fan Size | 4.72" |
| Installed Fan Size Details | 1 x 120mm |
| Fan Size Supported | 5.51" |
| Maximum CPU Cooler Height | 7.17" |
| Manufacturer | SilverStone Technology, Inc |
| Number of Fans Supported | 3 |
| Number of Fans Installed | 1 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 3 |
| Drive Bays | |
|---|---|
| Number of Internal 2.5" Bays | 3 |
| Number of Internal 3.5" Bays | 2 |
| Number of External 5.25" Bays | 1 |
| Miscellaneous | |
|---|---|
| Product Name | SUGO 14 Mini-ITX Cube Chassis with Powerful Accommodation |
