HDMI KVM Extender transmits HDMI 1080p and USB signals up to 230ft (70m) over single Cat6/7 cable with zero latency, and 4K@30Hz up to 130ft (40m), allows you to control computer from a remote location with a USB keyboard and mouse, HDCP 1.4, HDR 10, Reset Button, ESD Protection, Metal Housing
Extending HDMI and USB Signals
- Easily extend HDMI audio/video and USB signals up to 230ft (70m) through a Cat6/7 network cable to remote 1080p display with zero latency and 4K@30Hz transmission distance is up to 130ft (40m), allow you to use a one set of keyboard & mouse for remote control
Keyboard and Mouse Control
- Delivers three USB Type-A ports, two for independent HID keyboard & mouse to control your PC system from a remote location and one for Host connection such as Laptop or Desktop. It also supports wireless keyboard and mouse with a dongle plugged into the USB port
High Performance
- Offers a true 10.2Gbps video bandwidth and supports PCM 2/5.1/7.1-ch, Dolby 5.1/7.1-ch, DTS 5.1/7.1-ch audio formats
4K UHD Video Resolution
- Supports video resolution up to 1080p (1920x1080) @60Hz, 4K@30Hz, HDCP 1.4, HDR 10, YUV 4:4:4 8-bit to deliver a clear picture quality, and supports High Dynamic Range (HDR) 10 for enhanced video quality
Protection Components
- Supports ESD protection, lightning protection, and surge protection to safe your electronic equipment
Multiple Connectivity Ports
- Comes with one HDMI video input port, one USB Type-A port for PC host connection, one HDMI video output port, two USB Type-A ports for connecting keyboard and mouse, one RJ45 input port, one RJ45 output port, two DC 5V/1A power jack and two reset buttons
Maximum Compatibility
- Supports Plug-n-play and no driver installation required. The reset button allows displays to be re-detected if no displays are detected. Automatically adjusts parameters to match different network cables and achieve the best display performance
Compact Metal Housing Design
- It features a high-quality surface metal housing that efficiently dissipates heat, ensuring system stability and trouble-free operation
| Brand | |
|---|---|
| Brand | SIIG |
| GPU / Graphics | |
|---|---|
| Graphic Mode | 4K UHD |
| Power & Battery | |
|---|---|
| Input Voltage Range | 100-240V AC |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| Number of USB Ports | 3 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Ports | 2 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 2 |
| Network (RJ-45) | Yes |
| Number of Network (RJ-45) Ports | 2 |
| Camera / Webcam | |
|---|---|
| Maximum Video Resolution | 3840 x 2160 |
| Size / Dimensions | |
|---|---|
| Transmitter Weight (Approxima | 4.32 oz |
| Receiver Width | 3.03" |
| Receiver Weight (Approximate) | 4.32 oz |
| Receiver Height | 0.83" |
| Receiver Depth | 2.36" |
| Transmitter Depth | 2.36" |
| Transmitter Weight (Approximate) | 4.32 oz |
| Transmitter Height | 0.83" |
| Transmitter Width | 3.03" |
| General Features | |
|---|---|
| Frequency | 60 Hz |
| Maximum Operating Distance | 229.66 ft |
| Manufacturer | SIIG, Inc |
| Device Type | KVM Extender |
