Create pixel-perfect imagery with the high-end panel quality of the fully professional NEC M Series large format displays. By focusing on customer needs while also offering professional reliability, the M series displays give customers a digital signage display lineup without all the costs. The M series can support both landscape and portrait orientations while also allowing the modularity possibilities to customize their needs dependent on their application and use. The new series contain a full metal mechanical chassis, allowing for a more robust design necessary for commercial applications while maintaining the attractive aesthetics that allow the focus of onlookers to be on what matters - the message. Simple and targeted connectivity options allow customers to have the up-to-date options that they need while not having to overpay for excess and unused interfaces. The NEC M series boasts 500 cd/m² brightness which is ideal for a majority of digital signage applications in corporate, higher education, restaurant, retail and grocery store environments when the focus should be on the message, not the budget. Share your message, your way.
- 4K UHD native resolution allows for crystal clear imagery and messaging that become more vivid and lifelike than ever before!
- Landscape and Portrait orientation allows for flexibility of installation dependent on your needs
- Accepts Intel® Smart Display Module Small or Large allowing for sleek all-in-one intelligence and interoperability in a small form factor setting by accepting Intel processor-based products and other peripherals directly into the displays
- Bidirectional and Full External Control allows for easy integration into control systems via LAN or RS232C
- Raspberry Pi Compute Module 4 allows for future proof expansion directly into the display
- 500 cd/m² brightness and HDR compatibility will capture the attention of audience in almost any situation
- 24/7 commercial runtimes with built-in real-time clock and full scheduler capabilities
- Failover Capabilities with full Input Detect functionality allow peace of mind as the display will automatically switch to a secondary or tertiary source if the p
| Brand | |
|---|---|
| Brand | Sharp |
| GPU / Graphics | |
|---|---|
| Number of Screens | 1 |
| Screen / Display | |
|---|---|
| Native Contrast Ratio | 000:1 , 8 |
| Viewable Screen Size | 50" |
| Backlight Technology | Direct LED |
| High Dynamic Range (HDR) Type | HDR10 |
| High Dynamic Range (HDR) | Yes |
| Display Resolution | 3840 x 2160 |
| Display Screen Type | LCD |
| Aspect Ratio | 16:9 |
| Panel Technology | Vertical Alignment (VA) |
| Brightness | 500 Nit |
| Response Time | 6.50 ms |
| Pixel Pitch | 11.4 mil |
| Color Depth | 8-bit+FRC |
| Networking & Connectivity | |
|---|---|
| Ethernet | Yes |
| USB Ports | |
|---|---|
| USB | Yes |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Inputs | 2 |
| Number of HDMI 2.0 Ports | 2 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Size / Dimensions | |
|---|---|
| VESA Mount Standard | 400 x 400 |
| Mount Type | Table Mount |
| Orientation | Landscape/Portrait |
| Bezel Width (Top) | 0.55" |
| Bezel Width (Bottom) | 0.55" |
| Bezel Width (Left) | 0.55" |
| Bezel Width (Right) | 0.55" |
| Appearance | |
|---|---|
| Housing Material | Metal |
| General Features | |
|---|---|
| Operation Hours | 24 Hours/7 Days |
| Manufacturer | Sharp |
| Misc Ports | |
|---|---|
| Serial | Yes |
| RS-232C Input | Yes |
| Printer/Scanner/Fax Specs | |
|---|---|
| Scan Format | 2160p |
| Compliance & Certification | |
|---|---|
| Energy Efficiency Certificati | ENERGY STAR 8.0 |
| Maximum Storage Temperature | 140°F (60°C) |
| Minimum Storage Temperature | -4°F (-20°C) |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 20% |
| Minimum Storage Humidity | 10% |
| Maximum Storage Humidity | 90% |
| Energy Star | Yes |
