The Server Technology® PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® and POPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched POPS "Primary" PDU can be connected to as many as three (with optional module) PRO2 Switched POPS "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- Branch Circuit Protection: This PDU meets the UL and IEC 60950-1 requirement for branch circuit protection through use of UL489 ratedmagnetic-hydraulic circuit breakers or UL248 fuses.
- Branch Current Monitoring: Monitors current at each breaker branch and provides SNMPbased alerts and emails on high usage that risks a tripped circuit.
- Per-Outlet Power Sensing: Meets ANSI C12.1 for billing-grade accuracy of Current per phase. POPS includes voltage, active power, apparent power, power factor, and energy.
- Per-Inlet Power Sensing: Meets ANSI C12.1 for billing-grade accuracy of Current perphase. PIPS includes voltage, active power, apparent power, power factor, and energy.
- Auto-Flip Current Display: Easy-to-read LEDs display current per phase to help preventoverloads and simplify three-phase load balancing in highdensity cabinets.
- Temperature/Humidity Monitoring: Primary and Link units each support two external 10' (3m) T/H probes. Receive SNMP-based alerts and email notifications.
- Star Multi-Linking: Provides the
| Brand | |
|---|---|
| Brand | Server Technology |
| Power & Battery | |
|---|---|
| Power Rating (Watt) | 22 kW |
| PDU Type | Switched |
| Remote Outlet Switching | Yes |
| Phase | Three Phase |
| Receptacle Detail | 12 x CX |
| Receptacle Type | CX |
| Plug/Connector Type | IEC 60309 3P+N+PE 6Hr 32A |
| Input Voltage | 400 V AC |
| Input Current | 32 A |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mount Type | Cabinet-mountable |
| General Features | |
|---|---|
| Protection Type | Double Pole |
| Manufacturer | Legrand Group |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
