The Server Technology® PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® and POPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched POPS "Primary" PDU can be connected to as many as three (with optional module) PRO2 Switched POPS "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- Color-Coded Options
- Select from six colors to designate PDU circuits in the data center - black, white, red, green, blue, and yellow.
- PRO2 receptacles have high retention and are compatible with P-Lock type power cords.
- High Retention Locking Outlets
- Outlet Control
- On Switched PDUs, cycle power to individual outlets or groups of outlets to reboot servers, or power off unused receptacles.
- This PDU meets the UL and IEC 62368-1 requirement for branch circuit protection through UL 489 rated magnetic-hydraulic circuit breakers or UL 248 fuses.
- Branch Circuit Protection
- Monitors current at each breaker branch and provides SNMP-based alerts and emails on high usage that risks a tripped circuit.
- Branch Current Monitoring
- Per-Outlet Power Sensing
- POPS® (Per Outlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, and Energy per outlet.
- Per-Inlet Power Sensing
- PIPS® (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Appar
| Brand | |
|---|---|
| Brand | Legrand Group |
| Power & Battery | |
|---|---|
| Power Rating (Watt) | 5700 W |
| PDU Type | Switched |
| Phase | Three Phase |
| Receptacle Detail | 6 x CX |
| Receptacle Type | CX |
| Plug/Connector Type | NEMA L21-20P |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Input Current | 20 A |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Hot-swappable |
| Mount Type | Cabinet-mountable |
| General Features | |
|---|---|
| Environmental Sensors | Temperature/Humidity |
| Protection Type | Circuit Protection |
| Manufacturer | Legrand Group |
