- PDU provides power control as remote controlled relay & load monitoring
- Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- Single Phase phase PDU for reliable performance with maximum productivity
- NEMA L6-30P plug/connector type for better, dependable connectivity and desired power output
- 230 V AC input voltage for maximum feasibility and added productivity
- 208 V AC output voltage for optimal performance with maximum feasibility
| Brand | |
|---|---|
| Brand | Legrand Group |
| Power & Battery | |
|---|---|
| PDU Type | Monitored |
| Remote Outlet Switching | Yes |
| Phase | Single Phase |
| Receptacle Detail | 18 x IEC 60320 C19 |
| Receptacle Type | IEC 60320 C19 |
| Plug/Connector Type | NEMA L6-30P |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Input Current | 30 A |
| Power Rating (VA) | 5000 VA |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mount Type | Rack-mountable |
| Mounting Orientation | Vertical/Toolless |
| Rack Height | 0U |
| General Features | |
|---|---|
| Protection Type | Double Pole |
| Manufacturer | Legrand Group |
