Most Reliable
Rock Solid Uptime, No Compromises.
From the ground up, PX Intelligent PDUs are architected with components, features, and failsafes that ensure the most reliable infrastructure possible, both now and for years to come.
- Built-In Failover Power
- Advanced Alerting and Intelligence
- Circuit Breaker Trip Alarming
Built to Last
Prevent Outages Before They Occur
PX Intelligent PDUs help eliminate human error and can withstand the harshest environments. With monitoring features that spot problems in advance and physical design elements that adapt to the toughest conditions, our solution protects your critical load under any circumstances.
Easiest to Use
Simple to Deploy, Simple to Use.
Thoughtful design pays extraordinary dividends. Engineered with electricians, infrastructure managers, and IT experts in mind, PX Intelligent PDUs offer a simple user experience for seamless physical deployment, configuration, commissioning, monitoring, and power delivery.
- PDU improves efficiency, uptime and growth of data centers
- Remotely monitor single-or-three phase voltage, frequency even load levels with monitored PDUs
- IEC 60320 C19 receptacle type to ensure maximum usability and reliable power output
- Three Phase phase PDU provides optimal power output with added usability
- CS8365C (3P4W) plug/connector type for efficient connectivity and feasible power output
- 230 V AC input voltage for maximum feasibility and added productivity
- 208 V AC output voltage for maximum dependability and added productivity
| Brand | |
|---|---|
| Brand | Legrand Group |
| Power & Battery | |
|---|---|
| PDU Type | Monitored |
| Phase | Three Phase |
| Receptacle Detail | 18 x IEC 60320 C13 |
| Receptacle Type | IEC 60320 C13 |
| Plug/Connector Type | CS8365C (3P4W) |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC |
| Input Current | 50 A |
| Power Rating (VA) | 12.60 kVA |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mount Type | Rack-mountable |
| Mounting Orientation | Vertical |
| Rack Height | 0U |
| General Features | |
|---|---|
| Protection Type | Overcurrent Protection |
| Manufacturer | Legrand Group |
