Affordable | Enterprise-level Storage
Delivers an affordable high-performance SAS solution with advanced enterprise level reliability and functionality.
Four multipurpose SAS ports (SFF-8644) per controller for connecting upstream or downstream multiple cascaded JBODs for applications requiring huge bandwidth.
Fully redundant I/O modules, power supplies, and cooling units providing exceptional data availability for any size business environment.
Cable-less Storage Bridge Bay (SBB) design for Enterprise OEMs.
Data Center | Hybrid HDD/SSD Arrays
Flash arrays enable optimized speed for key enterprise applications that need processing power yet power savings.
Fully backward compatible with 6 Gb SAS/SATA devices, users have the ability to deploy 3/6/12 Gb SAS/SATA hard drives and SSDs in the J5000 Series.
Efficient power supplies provide up to 90% power efficiency that improves TCO by conserving power, reducing heat output and improving cooling costs.
Internal 12 Gb SAS expander-based architecture also allows for transparent access to each drive, enabling full utilization of the power management features built into modern hard drives.
Backup
As consumers and businesses become more mobile, the need for data access, retrieval, and distribution anywhere at any time means that data must be protected.
Data centers, hyperscale computing, and high-performance computing not only require performance and reliability, but flexibility and cost-efficiency for tiered storage management. Nearline SAS/SATA JBOD expansion units provide the versatility and scale for such demands.
- Compact in size but massive in performance. Provides sufficient external data storage, with ultra-fast data transfer speeds and configurable modes.
- Organize wires & secure cables for professional installation with rack mounting facility
| Brand | |
|---|---|
| Brand | Promise Technology |
| Storage | |
|---|---|
| Number of Solid State Drive I | 0 |
| Number of Hard Drives Install | 24 |
| Number of Hard Drives Support | 24 |
| Total Hard Drive Capacity Ins | 384 TB |
| Drive Interface | 12Gb/s SAS |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| General Features | |
|---|---|
| Maximum Data Transfer Rate | 12 Gbit/s |
| Manufacturer | Promise Technology |
| Drive Bays | |
|---|---|
| Number of Solid State Drive S | 24 |
| Number of Total Expansion Bays | 24 |
| Number of 3.5" Bays | 24 |
