The Pug PRO series is a 2X2 MIMO cellular, up to 2x2 MIMO Wi-Fi and optional GPS, omni-directional fixed wireless antenna. The Pug is designed for high performance of kiosks, vending machines, ATMs, and POTS replacement. This new package is adhesive mount, magnetic mount, or panel mount. No drilling required.
This PRO series IP67-rated antenna is small enough to mount and perform at high efficiency on POTS replacement boxes and other equipment using a magnetic and adhesive base.
- 2X2 MIMO CELLULAR
- UP TO 2x2 MIMO WI-FI
- OMNI-DIRECTIONAL
- OPTIONAL GPS
- 600 MHz - 6 GHz
- 3.98 in X 2.71 in X 3.08 in
- MAXIMUM 4:1 CONFIGURATION
| Brand | |
|---|---|
| Brand | Inc. , Parsec Technologies |
| Networking & Connectivity | |
|---|---|
| Antenna Gain | 7 dB |
| Frequency Band Type | RF |
| Audio | |
|---|---|
| Directivity | Omni-directional |
| Size / Dimensions | |
|---|---|
| Form Factor | Panel Mount |
| General Features | |
|---|---|
| Operating Frequency Range | 600 MHz to 6000 MHz |
| Manufacturer | Parsec Technologies, Inc. |
| Cables | |
|---|---|
| Connector Type | RP-SMA |
Parsec Pug Pro Antenna - Range - RF - 600 MHz to 6000 MHz - 7 dB - Cellular Network, Kiosk, Vending Machine, ATM Machine, IoT Device - Black - Adhesive Mount, Magnetic Mount, Panel Mount - Omni-directional - SMA, RP-SMA Connector
