The TX6000™ Cat 6 UTP copper cable is constructed of 23 AWG copper conductors with FEP/polyolefin (CMP) insulation. The copper conductors shall be twisted in pairs, separated by a cross-divider and covered by a low smoke, flame-retardant, plenum-rated, green jacket.
- Third party tested: Cable has been tested as part of the TX6000 U/UTP Copper Cabling System by an independent laboratory and complies with the electrical channel requirements of the following Standard: ANSI/TIA-568.2-D Category 6
- Guaranteed channel performance above the Standards: Industry leading guaranteed channel performance exceeds the TIA/ISO Standards with headroom guaranteed
- Integrated pair divider: Separates pairs for exceptional cable performance
- Reelex™ packaging: Compact carton ensures proper performance and provides quick installation
- Tested beyond the Standards: Cable has been characterized to 650 MHz, 400 MHz above the Standard
- Extended temperature range: Allows operation in 90°C (194°F) ambient environment providing error-free performance in high-density cabinets and large cable bundles running PoE+ or PoE++ applications
- Descending length cable markings: Easy identification of remaining cable reduces installation time and cable scrap
| Brand | |
|---|---|
| Brand | PANDUIT CORP |
| General Features | |
|---|---|
| Data Transfer Rate | 10 Gbit/s |
| Manufacturer | PANDUIT CORP |
| Cables | |
|---|---|
| Cable Shielding Type | Unshielded Twisted Pair (UTP) |
| Cable Length | 1000.66 ft |
| Cable Type | Category 6 |
| Connector Type on First End | Bare Wire |
| Connector Type on Second End | Bare Wire |
| Jacket Material | Polyvinyl Chloride (PVC) |
| Jacket Type | CMP-LP |
| Jacket Color | Green |
| Shielding | No |
| American Wire Gauge | 23 AWG |
| Number of Pairs | 4 |
| Number of Conductors | 8 |
| Insulation Material | Polyolefin |
