The vibration resistant male tab disconnect is made of brass and is nickel-plated. It is fully insulated in a red, nylon housing. It has a tab size of 0.250 x 0.032" (6.3 x 0.8 mm) and supports a wire range of 22-18 AWG (0.5-1.0 mm²). It is 0.90" (22.9 mm) long and 0.42" (10.7 mm) wide. The disconnect has a funnel entry barrel configuration and a butted seam barrel. It comes in bottles of 50.
- With easy crimp or screw options, terminal connectors reduce installation time in automotive and industrial setups
- Designed for harsh conditions, nickel plating offers corrosion protection and stable conductivity in demanding setups
| Brand | |
|---|---|
| Brand | PANDUIT CORP |
| General Features | |
|---|---|
| Manufacturer | PANDUIT CORP |
| Cables | |
|---|---|
| Connector Type | Quick Disconnect |
| Connector Details | 1 x Quick Disconnect |
| Contact Plating | Nickel |
| Insulation Material | Nylon |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
