High 4K image quality for clear and detailed visuals
With 500 cd/m2 brightness and antiglare surface (haze 25 %) panels to suppress the reflected glare of bright light, it is ideal for conference rooms and classrooms. The wide-viewing-angle panel delivers clear, high-quality images from any viewing position.
Flexible installation to suit a variety of use cases
The EQ3 Series is available in six sizes, ranging from 86-inch to 43-inch, and supports both portrait and landscape installation. With forward/backward tilt up to 20 degrees, it ensures clear visibility in any setup.
Scalability that enables cooperation with various systems
Equipped with three HDMI™ inputs, PC input, and USB Type-A ports, this device connects various external devices based on the usage environment. It also supports external control via RS-232C, LAN (PJLink™), enabling efficient operation.
Delivers stunning clarity and precise detail.
The EQ3 Series features an anti-reflective panel that minimizes glare from ambient light and room lighting. Even in brightly lit meeting rooms, it delivers high-resolution content with excellent visibility, enabling smooth and efficient information sharing.
Capable of extended operation and adaptable to diverse installation plans
The EQ3 Series is available in six sizes, ranging from 86-inch to 43-inch, and supports both portrait and landscape installation. It is capable of operating for up to 18 hours a day, making it reliable for use in environments that require long hours of operation, such as corporate reception areas and school bulletin boards.
Integrates with various systems depending on the usage environment
Equipped with three HDMI™ inputs and compatible with HDMI™-CEC control. You can perform basic operations of connected devices using the included remote control. In addition, centralized control and management are possible via LAN connection.
- Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
- Experience luminescent visual images with LCD display
- 3840x2160 Display - Delivers a breathtaking ultra HD viewing experience with immersive pictures that are dynamic, clear, and as expansive as life
- Engages your customers and makes their viewing experience breathtaking with its 2160p content
- Experience stunning picture result with cost-effective LED backlighting
| Brand | |
|---|---|
| Brand | Panasonic |
| GPU / Graphics | |
|---|---|
| Number of Screens | 1 |
| Screen / Display | |
|---|---|
| Native Contrast Ratio | 1 , 200:1 |
| Screen Size Class | 75" |
| Viewable Screen Size | 74.50" |
| Backlight Technology | LED |
| Display Resolution | 3840 x 2160 |
| Display Screen Type | LCD |
| Aspect Ratio | 16:9 |
| Brightness | 500 Nit |
| Response Time | 8 ms |
| Power & Battery | |
|---|---|
| Input Voltage | 230 V AC |
| Off-Mode Power Consumption | 300 mW |
| Networking & Connectivity | |
|---|---|
| Ethernet | Yes |
| USB Ports | |
|---|---|
| USB | Yes |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Inputs | 3 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Audio Ports | |
|---|---|
| Number of Audio Line Out | 1 |
| Size / Dimensions | |
|---|---|
| VESA Mount Standard | 600 x 400 |
| Mount Type | Wall Mountable |
| Mount Surface | Wall |
| Orientation | Landscape/Portrait |
| Bezel Width (Top) | 0.59" |
| Bezel Width (Bottom) | 0.59" |
| Bezel Width (Left) | 0.59" |
| Bezel Width (Right) | 0.59" |
| Security | |
|---|---|
| HDCP Version | 2.2 |
| General Features | |
|---|---|
| Operation Hours | 18 Hours/Day |
| Manufacturer | Panasonic |
| Misc Ports | |
|---|---|
| Serial | Yes |
| Printer/Scanner/Fax Specs | |
|---|---|
| Scan Format | 2160p |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 20% |
| Miscellaneous | |
|---|---|
| Installation Type | Hanging |
| Brand | Panasonic |
| UPC/GTIN | 885170449671 |
| MPN | TH-75EQ3W |
| Unit Count | 1 Units |
| Warranty | 3 Year |
| Return Policy | This product is eligible for 30-day returns subject to a restocking fee. See our return policy for details. |
