Control and Configure Beyond Plug-and-Play
NETGEAR Easy Smart Managed Switches with PoE+ meet the needs of growing businesses by providing fundamental network features such as simplified VLANs, QoS set-up and IGMP Snooping that help optimize the performance of the network. Easy Smart Managed Switches are the perfect upgrade from the basic Unmanaged Switches, delivering essential networking management features at a very affordable price. These models support Power-Over-Ethernet (PoE) and can power devices such as VOIP phones, surveillance IP cameras, wireless access points and many other PoE devices. These new Gigabit Ethernet PoE+ Easy Smart Managed Switch models include uninterruptable PoE to help optimize the performance and troubleshooting of business networks. The new and improved business-friendly GUI allows easy management and simple configuration. With the growing deployment of applications and an all-in-one solution, providing management and power to these applications would be ideal.
Highlights
- Enable network configuration and management at an affordable price
- Simple, yet useful network set-up on top of plug-and-play connectivity
- Business-friendly and easy-to-use mobile-device friendly web browser-based management GUI
- VLAN support for traffic segmentation
- Quality of Service (QoS) for traffic prioritization
- Auto "denial-of-service" (DoS) prevention
- Troubleshoot connection issues via cable test
- Loop prevention, loop detection, and broadcast storm controls
- Rate limiting for better bandwidth allocation
- Port mirroring for network monitoring
- Jumbo frame support
- Advanced features such as per port PoE controls
- Uninterrupted PoE keeps PoE power on even when the switch is updating firmware or performing a soft reboot
- 802.3at standard providing up to 30W per port
- Fanless with versatile mounting options (desktop and wall-mountable)
- Ethernet Switch supports increased network bandwidth availability through data switching
- Allows connection between separate networks to support infrastructure flexibility and structured traffic distribution
- Features 15 networking ports to establish a local wired network or extend connectivity within an existing layout
- Power Adapter power source supports consistent electrical supply for device operation
- Layer 3 switching support enables structured traffic management without altering established network architecture
- Desktop form factor supports placement outside dedicated wiring enclosures for accessible device positioning
- Managed capability enables configuration and monitoring functions that support structured network operation
- Gigabit Ethernet supports higher uplink data rates compared to standard Ethernet server connections
- Twisted pair cable support enables cost?efficient network connections for data transmission across distances
| Brand | |
|---|---|
| Brand | Netgear |
| Power & Battery | |
|---|---|
| PoE Budget | 180 W |
| Maximum Operating Power Consumption | 10.09 W |
| Power Source | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Network Technology | 10/100/1000Base-T |
| Switch Management Type | Easy Smart Managed |
| Layer Supported | 3 |
| Data Link Protocols | HTTP |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Total Number of Network Ports | 15 |
| PoE (RJ-45) Port | Yes |
| Uplink Port | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Enclosure |
| Maximum Height Adjustment (Above) | 1.1" |
| Appearance | |
|---|---|
| Color | Not Specified |
| General Features | |
|---|---|
| Manageable | Yes |
| Maximum Data Transfer Rate | 128 MB/s |
| Mean Time Between Failures (MTBF) | 784742 Hour |
| Manufacturer | Netgear, Inc |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 1 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 1 |
| Misc Ports | |
|---|---|
| Port/Expansion Slot Details | 1 x Expansion Slot |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Optical Fiber |
| Brand | Netgear, Inc |
| UPC/GTIN | 606449174823 |
| MPN | GS116EP-100NAS |
| Unit Count | 1 Units |
| Warranty | Lifetime |
| Return Policy | This product is eligible for 30-day returns. See our return policy for details. |
| Customer Reviews | 4.0 (1) |
