The N1C L-Series Lithium-Ion UPS systems are a game changer, offering maximum protection from all 9 power problems with their online double conversion topology, while also offering an industry-best 10-year full warranty on electronics and battery. The L-Series was the first full lineup of lithium-ion UPS systems on the market, and they remain a leader among lithium-ion systems, offering not only the best warranty in the business and competitive prices, but also some of the best on-battery runtimes. The 1kVA, 2kVA and 3kVA models all run for about 13 minutes at full capacity, while the 1.5kVA model runs for 18 minutes and the 2.2kVA models last an astonishing 24 minutes at full load! That's equivalent to many 2 or 2.2kVA lead acid UPS systems supported by an external lead acid battery pack! With N1C L-Series, you'll have the time to restore power or perform graceful shutdowns of connected equipment.
All N1C L-Series UPS systems offer long-life lithium iron phosphate (LiFePO4) battery technology with integrated battery management systems for safety and a 12-15 year design life in normal operating conditions. This lowers your overall total cost of ownership by virtually eliminating costly battery replacements (sourcing, shipping, downtime, maintenance, recycling, etc.) All systems offer a pure sine wave output and 0ms transfer time to battery to power and maintain even the most sensitive equipment. The always-included SNMP network monitoring card offers remote monitoring, alerting and shutdown capabilities, and our WiseFind/WiseClose/WiseInsight multi-UPS monitoring software suite is license free to all users. Dry contact relay cards are also available for interfacing with building control systems, PLC boards and other industrial gear.
- Industry-best 10-year warranty on electronics and battery
- Lithium-ion battery lowers total cost of ownership over lead acid systems by virtually eliminating costly battery replacements
- Lithium-ion battery offers 12-15 year design life and >2,000 charge/discharge cycles
- SNMP card included in all L-Series UPS models for remote network monitoring and alerts with FREE WiseInsight multi-UPS monitoring software
- Has one of the best runtimes in the industry at 13 minutes full load or 26 minutes half load
- UL1642, UL1778 (ETL), CSA C22.2 No. 107.3, UN38.3
| Brand | |
|---|---|
| Brand | N1 Critical Technologies |
| Power & Battery | |
|---|---|
| Phase | Single Phase |
| Input Frequency | 60 Hz |
| Overload Protection | Yes |
| EPO Port | Yes |
| Receptacle Detail | 8 x NEMA 5-15R |
| Receptacle Type | NEMA 5-15R |
| Plug/Connector Type | NEMA 5-15P |
| Battery Life | 15 Year |
| Battery Chemistry | Lithium-Ion (LiFePO4) |
| Battery Characteristics | Internal Battery |
| Typical Battery Recharge Time | 2 Hour |
| Input Voltage Range | 88 V AC - 148 V AC |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Efficiency Detail | >96% (ECO Mode) |
| Load Capacity (Watt) | 900 W |
| Load Capacity (VA) | 1000 VA |
| Input Power Factor | 0.9 |
| Output Frequency | 60 Hz |
| DC System Voltage | 36 V DC |
| Backup/Run Time (Full Load) | 13 Minute |
| Backup/Run Time (Half Load) | 26 Minute |
| Transfer Time | 0 ns |
| Waveform Type | Pure Sine Wave |
| Networking & Connectivity | |
|---|---|
| Network Management | SNMP |
| USB Ports | |
|---|---|
| USB | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack/Tower |
| Rack Height | 2U |
| General Features | |
|---|---|
| Alarm | UPS Failure |
| Manufacturer | N1 Critical Technologies, Inc |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Operating Humidity | 0% - 95% |
| Brand | N1 Critical Technologies, Inc |
| UPC/GTIN | 810318034389 |
| MPN | 10-500100 |
| Unit Count | 1 Units |
| Warranty | 10 Year |
