Microchip's PD-95xx-10GC is a family of Power over Ethernet (PoE) midspans offering 60W power per the IEEE802.3bt standard. The family is available in 6-, 12- and 24-port configurations. Input power is provided through a universal AC voltage connector. The product is designed for use with a standard 10/100/1000 and 10G BaseT Ethernet network over standard category 6A or better cabling, according to the IEEE802.3bt standard.
The PD-95xx-10GC family incorporates power management through Microchip's Powerview Pro software allowing the user to monitor and control the PD95xx-10GC via a remote network management station.
- Supports IEEE802.3bt type 3 standard PDs
- IEEE 802.3af/at backward compatible
- Legacy and pre-standard support
- 6, 12 and 24 ports
- Supports 10/100/1000 Mbps, 2.5/5/10 Gbps
- PowerView Pro, remote web-based SNMPv3 power management environment
| Brand | |
|---|---|
| Brand | Microchip Technology Inc. |
| Power & Battery | |
|---|---|
| Input Voltage | 230 V AC |
| Maximum Input Current | 12 A |
| Maximum Output Power | 60 W |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack Mountable |
| General Features | |
|---|---|
| Manufacturer | Microchip Technology Inc. |
| Misc Ports | |
|---|---|
| Output Ports | 24 x Gigabit Ethernet |
| Input Ports | 24 x Gigabit Ethernet |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Miscellaneous | |
|---|---|
| Product Name | PD-9524-10GC PoE Module |
