Managed Gigabit Ethernet PoE++ Switch 24 10/100/1000Base-T Ports + 2 100/1000Base-X SFP/RJ-45 Combo Ports

$ 2,414.49 $ 2,414.49
$ 2,414.49

$ 2,414.49 / Units
  • Brand
  • Depth
  • Weight (Approximate)
  • Height
  • Product Name
  • Marketing Information
  • Brand Name
  • Manufacturer Part Number
  • Width
  • Redundant Power Supply Suppor
  • Number of Power Supplies Inst
  • Network Technology
  • Manageable
  • Redundant Power Supply Supported
  • Features
  • Number of Power Supplies Installed
  • Network (RJ-45)
  • Total Number of Network Ports
  • PoE (RJ-45) Port
  • Total Number of Expansion Slots
  • Shared SFP Slot
  • Port/Expansion Slot Details
  • Form Factor
  • Maximum Data Transfer Rate
  • Ethernet Technology
  • Networking Standards
  • Layer Supported
  • Media Type Supported
  • Input Voltage
  • TAA Compliant
  • Package Contents
  • Limited Warranty
  • Manufacturer
  • Product Type
  • Product Series
  • Application/Usage
  • Manufacturer Website Address
  • Power Source
  • Power Consumption
Add to cart
Buy now
Add to wishlist
This product is eligible for 30-day returns. See our return policy for details. Terms and Conditions
Shipping: 1-6 Business Days
Contact Us

This switch is a high-performance Layer 2 managed switch with 52 Gbps switching capacity. It provides (24) 10/100/1000Mbps copper ports with IEEE 802.3bt PoE++ capability and (2) additional 100/1000Mbps dual speed SFP/RJ-45 combo ports.Integrated with Lantronix's Percepxion cloud based IoT edge solutions platform. NDAA Compliant, TAA Compliant

  • Hot-swappable dual power supply modules
  • Supports IPv4/IPv6 dual protocol stack
  • Supports Jumbo Frame up to 9K bytes
  • Authentication – RADIUS, TACACS+
  • Security – Supports SSH v1/SSH v2/SSL
  • Port based or tagged (IEEE 802.1Q) VLAN, MAC based,
  • Management VLAN and Private
  • VLAN Edge
  • DHCP Relay, DHCP Server
  • L2/L3/L4 ACLs Support MAC ACL, IP standard/extended ACL
  • LLDP (Link Layer Discovery Protocol)
  • IEEE 802.3az Energy Efficiency
  • IP Source Guard, Port Security
Brand
Brand Lantronix
Power & Battery
Redundant Power Supply Suppor Yes
Number of Power Supplies Inst 1
Redundant Power Supply Supported Yes
Number of Power Supplies Installed 1
Input Voltage 230 V AC
Power Source AC
Power Consumption 52 W
Networking & Connectivity
Network Technology 1000Base-X
Layer Supported 4
Ethernet Port
Network (RJ-45) Yes
Total Number of Network Ports 26
PoE (RJ-45) Port Yes
Size / Dimensions
Form Factor Rack-mountable
General Features
Manageable Yes
Maximum Data Transfer Rate 128 MB/s
Manufacturer Lantronix, Inc
Expansion Slots
Total Number of Expansion Slots 2
Shared SFP Slot Yes
Misc Ports
Port/Expansion Slot Details 1 x RJ-45 Console Port
Printer/Scanner/Fax Specs
Media Type Supported Optical Fiber
Compliance & Certification
TAA Compliant Yes
Managed Gigabit Ethernet PoE++ Switch 24 10/100/1000Base-T Ports + 2 100/1000Base-X SFP/RJ-45 Combo Ports - Managed PoE++ Switch, 24-port 10/100/1000Base-T PoE++ and 2 100/1000 SFP/RJ-45 Combo port, single 920 Watt power supply.
