Accurate and Vivid Colors
Featuring self-lighting pixels, the display maintains vivid colors and high contrast ratio even when the display becomes transparent. It brings content to life from wide viewing angles, and the content blends into its surroundings seamlessly and naturally.
Intuitive P-Cap Touch
By adding P-Cap touch sensor film to the display, the utilization possibilities expand to various industries where customer interaction services are demanding. Users could enjoy its fascinating content using their fingertips.
High Transparency
LG's OLED technology makes the Transparent OLED Touch Signage have slimmer structure without backlight unit nor a liquid crystal layer, achieving high transparency even with P-Cap touch film. While clearly showing objects behind the screen, it overlays the relevant information right before them.
Protective Tempered Glass
Touching a display directly can cause damage or scratches. The tempered front glass protects product from such external impacts and its anti-shatter glass is designed to minimize customers' injuries.
Enhanced Spatial Versatility
Experience the extraordinary with the state-of-the-art LG Transparent OLED Signage, which breaks down the barriers between the screen and surrounding environment, seamlessly connecting different spaces and people.
- Brightness (Typ.) : 200 / 600 nit (APL 100% / 25%, Without Glass)
- Transparency : 37% (Set)
- Bezel : 7.9 mm (T/R/L), 114.7 mm (B)
- Interface : HDMI / DP / USB 2.0 / Touch USB / RS232C / RJ45 / IR / Audio
- P-Cap Touch, Tempered Front Glass (3T)
| Brand | |
|---|---|
| Brand | LG Electronics |
| Screen / Display | |
|---|---|
| Dynamic Contrast Ratio | 000:1 , 200 |
| On Screen Display (OSD) Langu | Turkish |
| Protection Glass Transmission | 37% |
| Image Sticking Minimization ( | Yes |
| Touch Object Size Diameter | 0.31" |
| Accuracy Touch | 78.7 mil |
| Viewable Screen Size | 30" |
| Touchscreen | Yes |
| Multi-touch Screen | Yes |
| Display Resolution | 1366 x 768 |
| Aspect Ratio | 16:9 |
| Panel Technology | OLED |
| Brightness | 600 Nit |
| Response Time | 1 ms |
| Standard Refresh Rate | 120 Hz |
| Color Gamut | 110% BT.709 |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Color Depth | 10-bit |
| Power & Battery | |
|---|---|
| Power Consumption (DPM) | 0.5W |
| Input Voltage | 230 V AC |
| Off-Mode Power Consumption | 500 mW |
| Power Consumption | 86 W |
| Networking & Connectivity | |
|---|---|
| Infrared Output | Yes |
| Content Synchronization | RS-232C |
| Wireless LAN | No |
| Bluetooth | No |
| USB Ports | |
|---|---|
| USB Type-C | No |
| Number of USB 2.0 Ports | 1 |
| HDMI Ports | |
|---|---|
| Number of HDMI Inputs | 1 |
| DisplayPort | |
|---|---|
| DisplayPort In | Yes |
| DisplayPort Output | Yes |
| Number of DisplayPort Outputs | 1 |
| Ethernet Port | |
|---|---|
| Number of Network (RJ-45) Por | 1 |
| Audio Ports | |
|---|---|
| Number of Audio Line Out | 1 |
| Audio Line Out | Yes |
| Audio Line In | No |
| Audio | |
|---|---|
| Speakers | No |
| Input Devices | |
|---|---|
| Number of Simultaneous Touchp | 10 |
| Software & Licensing | |
|---|---|
| Embedded CMS | Local Contents Scheduling |
| Compatible Software | Mobile CMS |
| Size / Dimensions | |
|---|---|
| Front Glass Thickness | 0.16" |
| VESA Mount Compatible | No |
| Orientation | Landscape/Portrait |
| Bezel Width (Top) | 0.14" |
| Bezel Width (Bottom) | 0.91" |
| Bezel Width (Left) | 0.14" |
| Bezel Width (Right) | 0.14" |
| Appearance | |
|---|---|
| Bezel Color | Black |
| Surface Hardness | 5H |
| Security | |
|---|---|
| HDCP Version | 1.4/2.2 |
| General Features | |
|---|---|
| Operation Hours | 18 Hours/7 Days |
| Maximum Heat Generation | 310.2 kJ |
| Manufacturer | LG Electronics |
| Maximum LED Life | 3.4 Year |
| Video Ports | |
|---|---|
| DVI-D In | No |
| Misc Ports | |
|---|---|
| RS-232C Input | Yes |
| RS-232C Output | Yes |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 10% |
| Energy Star | No |
| Environmentally Friendly | Yes |
| Environmental Certification | ErP |
| Energy Efficiency Compliance | Energy-related Products Directive (ErP) |
