True Innovation behind New Depths
LG MAGNIT delivers immersive and eye-popping visuals that make every viewing experience memorable. Bring your imagination into life, through ultra-fine details visualized by a colourful mosaic of Micro LED chips.
Black Immersion, Enlivened Details
By removing a package surrounding R, G, B LED chips and applying LG's own Full Black Coating technology, LG MAGNIT surprisingly delivers much deeper black than the conventional package LED signage*. This not only enhances colour vividness, but also makes the details which were hidden in the shadows appear, providing audiences a sense of immersion.
Stronger Light and Shadow
The solid black LG MAGNIT makes also results in superbly high contrast ratio which is a vital part of the picture quality. The difference between the dark parts and the light parts is clearly great, making every part of the content distinctive.
Accurate Colours as Intended
By carefully selecting an LED chip which is a key factor to determine colour purity, its narrowed wavelength allows LG MAGNIT to show uniform colours across the screen. Furthermore, the enhanced Gamut Transfer technology supports it to describe colours close to the original colour, which is essential for places where exact colour representation is demanding.
Intelligent Image Processor
The Alpha 7 Intelligent Processor which is adopted from LG's TV technology recognizes and analyzes the original content, optimizing the clarity and sharpness of the content for itself.
Vivid Colour Expression Powered by HDR
With HDR (HDR10, HDR10 Pro) support, content becomes vivid with great visual impact. The wider colour spectrum and greater contrast ratio allow viewers to fully enjoy lively content.
Wide Colour Viewing Angle
Thanks to the structure of LG MAGNIT, it minimizes colour distortion according to the viewing angle. In other words, the original colour can be appreciated even from the side angles, captivating various pedestrians even if it is installed in a large public places.
Care Less with Sturdy Design
Through several layers of coated film, LG MAGNIT can protect its LED chips from risks caused by water drops, dust, static electricity or physical impacts. Considering that it is usually installed in public places where many people come and go, its stability is vitally important to minimize unforeseen accidents.
Sleek Look with Smooth Surface
The screen surface of LG MAGNIT is very smooth just as LCD, making it looks nice even when the screen is off. Also, audiences or installers feel soft when touching the screen. If fingerprints are on the surface, they can be simply removed by wiping with a soft cloth without the need for any chemicals.
Optimum Cable-less Design for Simple Installation
The Cable-less Signal Transmission technology has been adopted. No signal and power cable connection is required between the cabinets and you don't need cables except for connecting the screen to its system controller and power.
Efficient Power Consumption by Colours
Common Cathode Drive-IC is one of the reasons why LG MAGNIT has low power consumption. It supplies the right necessary voltage to each R, G, B sub-pixel individually to minimize unnecessary power consumption.
- Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
- 768 x 432 display resolution for reliable results with precision and clarity
| Brand | |
|---|---|
| Brand | LG Electronics |
| Screen / Display | |
|---|---|
| Color Uniformity | Cy , ±0.02 Cx |
| Dynamic Contrast Ratio | 000:1 , 150 |
| Minimum Color Temperature | 5300.3°F (2926.8°C) |
| Maximum Color Temperature | 16280.3°F (9026.8°C) |
| Physical Pixel Density | 1638400 pixels/m² |
| LED Type | Standard COB |
| Frame Refresh Rate | 60 Hz |
| High Dynamic Range (HDR) Type | HDR10 Pro |
| High Dynamic Range (HDR) | Yes |
| Display Resolution | 768 x 432 |
| Brightness | 500 Nit |
| Standard Refresh Rate | 3.84 kHz |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 160° |
| Pixel Pitch | 30.7 mil |
| Module Resolution | 192 x 216 |
| Power & Battery | |
|---|---|
| Heat Dissipation | 135.11 W |
| Average Heat Dissipation Per | 109.90 W |
| Input Voltage | 230 V AC |
| Size / Dimensions | |
|---|---|
| Module Height | 6.65" |
| Module Width | 5.91" |
| Cabinet Surface Area | 2 Sq. ft. |
| Weight per Square Meter (Appr | 37500 g/m² |
| Weight per Module (Approximat | 5.60 oz |
| Weight per Cabinet (Approxima | 17 lb |
| Appearance | |
|---|---|
| Housing Material | Die-cast Aluminum |
| General Features | |
|---|---|
| Service Access | Rear |
| Number of Modules Per Cabinet | 4x2 |
| Manufacturer | LG Electronics |
| Maximum LED Life | 11.4 Year |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Humidity | 80% |
| Minimum Operating Humidity | 10% |
| TAA Compliant | No |
| Environmentally Friendly | Yes |
| Ingress Protection (IP) Rating | IP20 |
