Internal Front Calibration Sensor | Consistency in Medical Images
The front-sensor, supported by calibration software, allows calibration without the need for additional measuring equipment, and helps maintain stable image quality.
Focus View Mode | Fully Focus on the Region of Interest
The 24HR513C-B features Focus View Mode which highlights specific parts of the medical image. Users can easily select and focus on areas of concern while darkening the rest of the screen.
Pathology Mode | As if Looking at a Microscope
With Pathology Mode, the 24HR513C-B provides image clarity and accuracy as if you were looking at a microscope.
Daisy Chain | Simple Connection for a Clutter-Free Workspace
Daisy Chain Setup helps to enable a productive workspace. You can connect a 24HR513C-B with two 3MP diagnostic monitors, displaying patient charts on the 24HR513C-B and medical images on two 3MP monitors.
Ergonomic Design | Customizable Workstation for Enhanced Usability
The 24HR513C-B is designed to be adjustable for the posture of users' image review. The One-Click Stand makes the installation process simple. The ergonomically designed stand allows users to freely adjust the tilt, height, and swivel. It also features a bi-directional auto pivot function for added flexibility.
Auto Luminance Sensor | Automatically Adjusts Screen Brightness
The 24HR513C-B features an Auto Luminance Sensor which sets screen brightness properly for the ambient lighting.
- General Radiology Viewing
- Internal Front Calibration Sensor
- Focus View Mode & Pathology Mode
- Convenient Management with LCS* Medical
- Supports Daisy Chain & Variety of Interfaces
- User-friendly Monitor Stand with Bi-Directional Auto Pivot Support
| Brand | |
|---|---|
| Brand | LG Electronics |
| GPU / Graphics | |
|---|---|
| Number of Screens | 1 |
| Screen / Display | |
|---|---|
| Contrast Ratio | 000:1 , 1 |
| Pivot | Yes |
| Adjustable Display Pivot | Yes |
| Screen Size Class | 24" |
| Viewable Screen Size | 24" |
| Aspect Ratio | 16:10 |
| Panel Technology | In-plane Switching (IPS) Technology |
| Brightness | 600 Nit |
| Response Time | 5 ms |
| Horizontal Viewing Angle | 178° |
| Vertical Viewing Angle | 178° |
| Screen Surface | Anti-glare |
| Response Time Details | 5 ms Fast |
| Power & Battery | |
|---|---|
| Input Voltage Range | 120V to 230V |
| Maximum Power Consumption | 65 W |
| USB Ports | |
|---|---|
| Number of USB 3.0 Upstream Po | 2 |
| USB | Yes |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Inputs | 1 |
| DisplayPort | |
|---|---|
| DisplayPort Input | Yes |
| DisplayPort | Yes |
| DisplayPort Output | Yes |
| Number of DisplayPorts | 1 |
| Size / Dimensions | |
|---|---|
| Weight with Stand (Approximat | 15.65 lb |
| VESA Mount Compatible | Yes |
| VESA Mount Standard | 75 x 75 |
| Maximum Adjustable Height | 5.91" |
| Tilt Angle | -5° to 25° |
| Appearance | |
|---|---|
| Adjustable Stand | Yes |
| General Features | |
|---|---|
| Swivel Angle | -45° to 45° |
| Pivot Angle | 90° |
| Frequency | 60 Hz |
| Manufacturer | LG Electronics |
