Introduction
ThinkSystem TruDDR5 and TruDDR4 memory delivers trusted, tested, quality, performance, and reliability throughout the ThinkSystem portfolio. We use the highest quality industry-standard memory components sourced from Tier 1 DRAM suppliers. Only memory that meets these strict requirements are selected for memory in Lenovo servers. It is then compatibility tested and tuned on every ThinkSystem server to maximize reliability.
In addition, Lenovo memory DIMMs for servers have a unique signature programmed into them so your system can verify that TruDDR4 Memory is installed in your system. Since the memory will be authenticated, memory stretch goals are enabled only when TruDDR4 Memory DIMMs are detected. Together with lower power consumption, these new DIMMs can provide the lowest TCO for data centers.
High Performance Memory
Lenovo offers high-performance and high-capacity memory options in ThinkSystem servers.
Persistent Memory
Lenovo ThinkSystem servers configured with Intel Optane Persistent Memory transforms the memory/storage hierarchy enabling faster insights from data. This breakthrough technology delivers large capacity, high speed, affordable memory with data persistence and advanced encryption capabilities. These modules significantly increase the capacity of available system memory, keeping more hot data closer to the CPU, and enabling greater operational efficiency by processing larger data sets with more user instances.
3DS RDIMMs
To meet the ever increasing demand for higher density server memory modules, Lenovo offers 3DS (3 Dimensional Stacked) DDR4 RDIMMs which apply TSV (Through Silicon Via) technology from our partnership with a leading Tier 1 DRAM supplier. The new TSV 3DS stack technology enables higher density DRAM stack packages with higher operational frequency and reduced power consumption. The RDIMM configuration along with 3DS TSV DRAM packages exhibits performance benefits and lower power consumption over alternative high density solutions to ultimately provide the lowest TCO for data centers.
- Allow convenient and fast access to the stored information your computer is actively using for maximum efficiency
- Up to 2933 MHz speed with registered signal for playing the latest games and using heavy software
- DIMM 64 GB of memory to maintain symmetry with processor and hard drive and bring out the ultimate computing experience
- TruDDR4 memory delivers performance and reliability for all of your workloads
- 288-pin for optimal performance and maximum reliability
- Server device support for your RAM Module to allow enhanced system performance and reliable memory solution
- DIMM form factor with 288-pin and 64 GB memory size effectively lessens the electrical load on the memory controller to allow maximum feasibility
- Registered signal processing provides increased processing power to allow maximum productivity
| Brand | |
|---|---|
| Brand | Lenovo Group Limited |
| Memory / RAM | |
|---|---|
| Memory Size | 64 GB |
| Memory Technology | TruDDR4 |
| Memory Speed | 2933 MHz |
| Memory Standard | DDR4-2933/PC4-23466 |
| Memory Voltage | 1.20 V |
| Number of Pins | 288-pin |
| Error Checking | ECC |
| Signal Processing | Registered |
| Size / Dimensions | |
|---|---|
| Form Factor | DIMM |
| General Features | |
|---|---|
| Manufacturer | Lenovo Group Limited |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
