The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Primary" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
- PDU allows power to be more efficiently distributed and controlled
- Remotely control individual outlets for rebooting of locked equipment with switched PDUs
- IEC 60320 C13 receptacle type to ensure maximum dependability and optimal performance
- Three Phase phase PDU provides dependable power output with maximum efficiency
- IEC C20 100-240V Inlet plug/connector type for reliable, productive connectivity and optimal power output
- 120 V AC input voltage for optimal performance with maximum usability
| Brand | |
|---|---|
| Brand | Legrand Group |
| Power & Battery | |
|---|---|
| PDU Type | Switched |
| Remote Outlet Switching | Yes |
| Phase | Three Phase |
| Input Frequency | 60 Hz |
| Circuit Breaker | Yes |
| Receptacle Detail | 8 x IEC 60320 C13 |
| Receptacle Type | IEC 60320 C13 |
| Plug/Connector Type | IEC C20 100-240V Inlet |
| Locking Receptacles | P-Lock |
| Input Voltage Range | 120 V AC - 240 V AC |
| Input Voltage | 230 V AC |
| Output Voltage Range | 220 V AC - 240 V AC |
| Input Current | 16 A |
| Load Capacity (Watt) | 3300 W |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mount Type | Cabinet-mountable |
| Rack Height | 1U |
| General Features | |
|---|---|
| Protection Type | Double Pole |
| Manufacturer | Legrand Group |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 140°F (60°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Storage Temperature | 185°F (85°C) |
| Minimum Storage Temperature | -40°F (-40°C) |
| UL Listed | Yes |
