Thunderbolt™ 4 Technology
Transfers up to 40Gbps of data, video, and audio. Provides daisy chain support for SSDs, monitors, and other Thunderbolt™ devices. Blocks peripheral devices from unauthorized access to your system memory using Intel VT-d DMA protection. Includes two 2.6ft (0.8m) Thunderbolt™ 4 cables. Compatible with Thunderbolt™ devices running Windows 11 or above.
Thunderbolt™ Share
Easily connects two Thunderbolt™-enabled devices (PCs, laptops, tablets) so you can be more productive. Provides a simple and cost-effective solution for fast PC-to-PC file transfers and allows you to effortlessly share peripherals, such as displays, keyboards, mice, external drives, and more.
Single 8K or Dual 4K Support for Thunderbolt™ Devices
Extend visual productivity with the resolution, contrast, and color depth of Ultra HD. Supports up to Single 8K @ 60Hz via a Thunderbolt™ 4 port or Dual 4K @ 60Hz via two HDMI® ports.
Up to 100W (96W certified) of dynamic Power Delivery
Delivers power whenever and wherever you need it-to host and connected accessories. Supports up to 100W (96W certified) of Power Delivery and provides optimal performance under any usage scenario.
Productive 13-in-1 Design
Extend your productivity with two HDMI® ports, one Thunderbolt™ 4 port, one Thunderbolt™ 4 host port, one USB-C® 3.2 Gen2 10Gbps port, two USB-A 3.2 Gen2 10Gbps ports, two USB-A 3.2 Gen1 5Gbps ports, one Gigabit Ethernet port, one audio combo jack, and two UHS-II 4.0 SD and Micro SD card readers.
Zero-Footprint Mounting Option and Security Cable Lock Slots
Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.
Free Kensington DockWorks™ Software and 3-Year Limited Warranty
Free DockWorks™ software delivers the best connection, performance, and security from your Kensington dock. Enjoy peace of mind knowing you are covered by Kensington with a professional warranty.
Sustainability Attributes
The SD5768T is composed of 100% post-consumer recycled (PCR) aluminum and up to 68% PCR plastic -and it is delivered in Forest Stewardship Council (FSC®) certified packaging. The outer top casing of the docking station is made of aluminum, excluding the PCBA and any related internal components. Does not include the cable, power supply, or power cord.
- Thunderbolt® 4 technology transfers up to 40Gbps of data, video, and audio, delivers daisy chain support, and provides Intel VT-d DMA protection.
- Compatible with Thunderbolt™ devices running Windows 11 or above.
- Thunderbolt™ Share provides a simple and cost-effective solution for fast PC-to-PC file transfers and allows you to effortlessly share peripherals, such as displays, keyboards, mice, external drives, and more.
- Supports up to Single 8K @ 60Hz via a Thunderbolt™ 4 port or Dual 4K @ 60Hz via two HDMI® ports.
- Supports up to 100W (96W certified) of Power Delivery to the host and connected accessories.
- Productive 13-in-1 design allows users to work more efficiently and connect to a variety of peripherals.
- Zero-footprint mounting option support a tidier workspace.
- Security cable lock slots support device protection.
- 3-Year limited warranty.
- The SD5768T is composed of 100% post-consumer recycled (PCR) aluminum and up to 68% PCR plastic -and it is delivered in Forest Stewardship Counc
| Brand | |
|---|---|
| Brand | Kensington Computer Products Group |
| GPU / Graphics | |
|---|---|
| Number of Displays Supported | 2 |
| Screen / Display | |
|---|---|
| Screen Mode Supported | 4K @ 60Hz |
| Supported Resolutions | 1920 x 1080 |
| Power & Battery | |
|---|---|
| Charging Capability | Yes |
| Maximum Power Supply Wattage | 149.10 W |
| Power Source Type | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| Number of USB 3.2 Gen 1 Type- | 2 |
| Number of USB 3.2 Gen 2 Type- | 2 |
| USB Power Delivery | 96W |
| Total Number of USB Ports | 5 |
| USB Type-C | Yes |
| Number of USB Type-C Ports | 1 |
| USB Type-A | Yes |
| Number of USB Type-A Ports | 4 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Outputs | 2 |
| Thunderbolt Ports | |
|---|---|
| Thunderbolt 4 | Yes |
| Number of Thunderbolt 4 Ports | 2 |
| Thunderbolt Ports Quantity | 2 |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Audio Ports | |
|---|---|
| Headphone/Microphone Combo Po | Yes |
| Card Reader | |
|---|---|
| Memory Card Reader | Yes |
| Memory Card Supported | microSD |
| Size / Dimensions | |
|---|---|
| Form Factor | Desktop |
| Appearance | |
|---|---|
| Color | Space Gray |
| Security | |
|---|---|
| Security Slot Type | Nano Security Slot |
| Kensington Security Slot | Yes |
| General Features | |
|---|---|
| Maximum Data Transfer Rate | 5 GB/s |
| Manufacturer | Kensington Computer Products Group |
| Misc Ports | |
|---|---|
| Total Number of Ports | 13 |
| Host Interface | Thunderbolt 4 |
| Cables | |
|---|---|
| Cable Length | 2.62 ft |
| Packaging & Origin | |
|---|---|
| Package Type | Retail |
| Brand | Kensington Computer Products Group |
| UPC/GTIN | 085896353812 |
| MPN | K35381NA |
| Unit Count | 1 Units |
| Warranty | 3 Year |
| Return Policy | This product is eligible for 30-day returns. See our return policy for details. |
