Boost Your Productivity with Thunderbolt™ 5
SD5010T5 offers lightning-fast data transfers, achieving speeds up to 80Gbps and Bandwidth Boost providing up to 120Gbps for video-intensive usage.
Triple 4K or Dual 8K for Windows and Dual 6K+4K for macOS
Supports up to 3 x 4K monitors @ 144Hz or 2 x 8K @ 60Hz/30Hz monitors for Windows laptops via two HDMI® ports and one Thunderbolt™ 5 port. For MacBook models with M4/M5 base chips* and M-Series Pro and Max chipsets, it supports 2 x 4K @ 60Hz via two HDMI® ports, or you can switch one of the displays to up to 6K through the Thunderbolt™ 5 port. *M1/M2 base chips support a single external display only. M3 base supports two external displays with the lid closed.
Up to 140W Dynamic Power Delivery + KonstantCharge™
Perfect for demanding workstations, this single-cable Thunderbolt™ 5 dock supports USB-C® PD 3.1, ensuring seamless power and connectivity with up to 140W dynamic power delivery. Includes KonstantCharge™, enabling connected devices to charge even when your laptop is undocked.
13-in-1 Design
A single Thunderbolt™ 5 cable expands your connectivity: 2 x Thunderbolt™ 5 (host + 15W downstream), 2 x HDMI®, 1 x USB-A 3.2 Gen2 10Gbps, 2 x USB-A 3.2 Gen1 5Gbps, 2 x USB-C® Gen2 10Gbps (1 x 30W), an audio combo jack, 2 x SD/Micro SD 4.0 slots, and 2.5Gbps Ethernet.
Built-in SD and Micro SD Card Readers
Perfect for graphic designers, video editors, and animators requiring fast and efficient data transfer speeds, the SD5010T5 transfers files at ultra-fast speeds via built-in SD and Micro SD 4.0 card readers.
Universal Compatibility
Offers a quick and powerful plug-and-play solution for Thunderbolt™ 5, Thunderbolt™ 4, USB4®, and USB-C® devices running Windows 11 (23H2 or later) or macOS (14.5 or later).
Zero-Footprint Mounting Option and Security Cable Lock Slots
Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.
Free Kensington DockWorks™ Software and 3-Year Limited Warranty
Free DockWorks™ software for Windows users delivers the best connection, performance, and security from your Kensington dock. Backed by Kensington with a 3-year limited warranty.
Sustainability Attributes
The outer case of this docking station contains 100% post-consumer recycled (PCR) aluminum - and it is delivered in Forest Stewardship Council (FSC®) certified packaging.
- Data transfer speeds up to 80Gbps.
- Bandwidth Boost offers up to 120Gbps for video-intensive usage.
- Up to Triple 4K or Dual 8K for Windows and Dual 6K+4K for macOS.
- Up to 140W dynamic Power Delivery for laptop and connected devices.
- 13-in-1 design supports seamless connectivity for a variety of setups.
- Bulit-in SD and Micro SD card readers provide ultra-fast file transfers.
- Plug-and-play for Thunderbolt™ 5, Thunderbolt™ 4, USB4®, and USB-C® devices.
- Windows 11 (23H2 or later) or macOS (14.5 or later).
- Zero-footprint mounting option for tidier workspace .
- Security cable lock slots compatible with Kensington laptop locks.
| Brand | |
|---|---|
| Brand | Kensington Computer Products Group |
| GPU / Graphics | |
|---|---|
| Number of Displays Supported | 3 |
| Screen / Display | |
|---|---|
| Screen Mode Supported | 6K |
| Supported Resolutions | 7680 x 4320 |
| Power & Battery | |
|---|---|
| Charging Capability | Yes |
| Maximum Power Supply Wattage | 180 W |
| Power Source Type | Power Adapter |
| Networking & Connectivity | |
|---|---|
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| Number of USB 3.2 Gen 1 Type- | 2 |
| Number of USB 3.2 Gen 2 Type- | 1 |
| USB Power Delivery | 140W |
| Total Number of USB Ports | 5 |
| USB Type-C | Yes |
| Number of USB Type-C Ports | 2 |
| USB Type-A | Yes |
| Number of USB Type-A Ports | 3 |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Number of HDMI Outputs | 2 |
| Thunderbolt Ports | |
|---|---|
| Number of Thunderbolt 5 Ports | 2 |
| Thunderbolt 5 | Yes |
| Thunderbolt Ports Quantity | 2 |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Number of RJ-45 Ports | 1 |
| Audio Ports | |
|---|---|
| Headphone/Microphone Combo Po | Yes |
| Card Reader | |
|---|---|
| Memory Card Reader | Yes |
| Memory Card Supported | microSD |
| Size / Dimensions | |
|---|---|
| Form Factor | Desktop |
| Security | |
|---|---|
| Security Slot Type | Kensington Security Slot |
| Kensington Security Slot | Yes |
| General Features | |
|---|---|
| Maximum Data Transfer Rate | 10 GB/s |
| Manufacturer | Kensington Computer Products Group |
| Brand Compatibility | Apple |
| Misc Ports | |
|---|---|
| Total Number of Ports | 13 |
| Host Interface | Thunderbolt 5 |
| Cables | |
|---|---|
| Cable Length | 3.30 ft |
| Packaging & Origin | |
|---|---|
| Package Type | Retail |
