Design Philosophy
A small 11.5L SFF chassis with optimal thermal and acoustic performance.
High Compatibility
It is compatible with standard desktop components, which makes the installation easier and provides a great expandability when needed.
Detachable Drive Bay Cage
For easy installation
Multi-Enjoyment
Designated Infrared Receiver position to support Media Center and optional internal amplifier.
Tool-Free
Screwless Expansion Slots Clip
Optional screwless design
- ODD/FDD/HDD bays, expansion slots, and side cover clips for easy installation.
Screwless ODD Bay Clips
Screwless Top Cover Clips
Screwless FDD/HDD Bays Clips
Excellent Thermal Solution
PPCT
The innovative partition plate cooling technology (PPCT) maximizes performance while providing a quiet and cooling environment.?Cooling Fan
Cooling Fan
Built-in 80x80x25mm fan for better system cooling.
Optional
- Supports 2.5" x 2
- Optional 60 mm Fan x 1 (60 x 60 x 10 mm, 2500rpm, 20dB Fan, 4 Pin Power Connector)
- Removable Air Filter
- Keylock Side Panel: The side panel is a theft deterrent key lock set for safeguarding your chassis equipment from unauthorized access.
- Security Screw with Keylock: Features a universal anti-theft design suitable for various computer cases, allowing for easy installation.
- Supports micro ATX motherboard to provide a significant number of PCI slots, expansion slots and peripheral ports with enhanced heat dissipation capability
- 5 bays help in upgrading the system by increasing number of hardware components
- Handy configuration ultra small offers quick upgrades and saves time and maintenance cost
| Brand | |
|---|---|
| Brand | In Win Development |
| GPU / Graphics | |
|---|---|
| Maximum GPU Length | 7.68" |
| Power & Battery | |
|---|---|
| Number of Power Supplies Supp | 1 |
| Number of Power Supplies Inst | 1 |
| Power Supply Wattage | 450 W |
| Power Supply Installed | Yes |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 4 |
| Front USB | Yes |
| USB Port Details | 4 x USB 2.0 |
| Audio Ports | |
|---|---|
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Ultra Small |
| General Features | |
|---|---|
| Motherboard Supported | Mini ITX |
| Cooler Type | Fan Cooler |
| Installed Fan Size | 3.15" |
| Installed Fan Size Details | 1 x 80mm |
| Fan Size Supported | 3.15" |
| Maximum CPU Cooler Height | 2.83" |
| Manufacturer | In Win Development, Inc |
| Number of Fans Supported | 1 |
| Number of Fans Installed | 1 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 4 |
| Drive Bays | |
|---|---|
| Number of Total Expansion Bays | 5 |
| Number of Internal 2.5" Bays | 1 |
| Number of External 3.5" Bays | 1 |
| Number of Internal 3.5" Bays | 2 |
| Number of External 5.25" Bays | 1 |
