The Aruba 8325 Switch Series offers a flexible and innovative approach to addressing the application, security, and scalability demands of the mobile, cloud and IoT era.These switches serve the needs of the next generation core and aggregation layer, as well as emerging data center requirements at the Top of Rack (ToR) and End of Row (EoR).They provide over 6.4Tbps of capacity, with line-rate Gigabit Ethernet interfaces including 10Gbps, 25Gbps, 40Gbps, and 100Gbps.
The 8325 series includes industry-leading line rate ports 1/10/25GbE (SFP/SFP+/SFP28) and 40/100GbE (QSFP+/QSFP28) with connectivity in a compact 1U form factor. These switches offer a fantastic investment for customers wanting to migrate from older 1GbE/10GbE to faster 25GbE, or 10GbE/40GbE to 100GbE ports.
- Compact 1U switch with 1/10/25GbE and 40/100GbE connectivity
- Advanced Layer 2/3 feature set includes BGP, 0SPF, VRF, and IPv6
- ArubaOS-CX automation and programmability using built-in REST APIs and Python scripts
- Designed for core/aggregation in the campus or top of Rack or End of Row in the data center
- High availability with industry-leading VSXredundancy, and redundant power supplies and fans
- Intelligent monitoring and visibility with Aruba network analytics engine
- High performance 6.4Tbps with 2,000 Mpps
| Brand | |
|---|---|
| Brand | Hewlett Packard Enterprise |
| Power & Battery | |
|---|---|
| Redundant Power Supply Suppor | Yes |
| Power Consumption | 550 W |
| Networking & Connectivity | |
|---|---|
| Network Technology | 100GBase-X |
| Layer Supported | 3 |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Compatible Rack Unit | 1U |
| Appearance | |
|---|---|
| Modular | Yes |
| General Features | |
|---|---|
| Manageable | Yes |
| Manufacturer | Hewlett Packard Enterprise |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 56 |
| Expansion Slot Type | SFP28 |
| Misc Ports | |
|---|---|
| Port/Expansion Slot Details | 8 x 100 Gigabit Ethernet Expansion Slot |
| Printer/Scanner/Fax Specs | |
|---|---|
| Media Type Supported | Optical Fiber |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
