Black Coating Technology
COB products are sealed with black epoxy resin on the surface, which guarantees a uniform colour.
Better Protection
Compared to SMD packaging, COB is one-piece potting sealing to protect important electronic devices. The display screen has the advantages of moisture-proof and anti-static, you can directly wipe the screen with water.
Automatic PQ Adjustment
Hisense XIH series, the spare lamp board can be directly replaced, intelligent reading lamp board data, automatically complete the colour correction.
Extremely Reliable
Flip-chip COB LED with no solder lines and electrodes directly welded to the PCB. No need to worry about the problem of easy breakage of the solder wire, it's more reliable.
Quick Installation and Easy Maintenance
Full front installation, maintenance, save the installation space. Also supporting multiple installations, wall-mounting, hanging, which can meet the demands of various environments
- Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
- Experience luminescent visual images with LCD display
- 480 x 270 display resolution for dependable display results with maximum efficiency
- LED backlighting offers a fine uniformity to display effective pictures at a low cost
| Brand | |
|---|---|
| Brand | Hisense Company Limited |
| Screen / Display | |
|---|---|
| Backlight Technology | LED |
| Display Resolution | 480 x 270 |
| Display Screen Type | LCD |
| Brightness | 1000 Nit |
| Pixel Pitch | 49.2 mil |
| Module Resolution | 120 x 135 |
| Size / Dimensions | |
|---|---|
| Mount Type | Wall Mountable |
| Appearance | |
|---|---|
| Housing Material | Die-cast Aluminum |
| General Features | |
|---|---|
| Indoor/Outdoor | Indoor |
| Manufacturer | Hisense Company Limited |
| Maximum LED Life | 11.4 Year |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 113°F (45°C) |
| Minimum Operating Temperature | 14°F (-10°C) |
| Ingress Protection (IP) Rating | IP65 |
