Designed for High Density and Flexibility
The Ultrastar Data60 hybrid storage platform is a key element of next-generation disaggregated storage and Software-Defined Storage (SDS) systems. The compact, efficient form factor provides the flexibility to specify the HDD and SSD combinations for balancing capacity, performance, and cost.
A flash data acceleration tier can be enabled to serve both fast data and big data applications from a single platform. The Ultrastar Data60 addresses the demanding storage needs of large enterprise customers, storage OEMs, cloud service providers, as well as resellers/integrators requiring dense, shared HDD or hybrid storage.
Designed for Big Data
High Density
Up to 720TB raw capacity in a 4U enclosure
Flexible
Choice of SAS or SATA with option for a flash data acceleration tier
Innovative
IsoVibe and ArcticFlow for improved performance, cooling, and TCO
- 5-year limited warranty
- Enterprise-grade redundant and hot-swappable PSUs, I/O modules, and fans
- Dual-port SAS for high availability or single-port SATA for low cost
- Up to 720TB raw capacity in 4U
- Hybrid support for data acceleration tier with SSDs (SAS or SATA) in up to 24 of 60 drive slots
- Up to 60 Ultrastar DC HC520 HDDs (SAS or SATA)
| Brand | |
|---|---|
| Brand | Western Digital Corporation |
| Storage | |
|---|---|
| Number of Hard Drives Install | 60 |
| Number of Hard Drives Support | 60 |
| Total Hard Drive Capacity Ins | 720 TB |
| Size / Dimensions | |
|---|---|
| Form Factor | Rack-mountable |
| Rack Height | 4U |
| General Features | |
|---|---|
| Manufacturer | Western Digital Corporation |
| Drive Bays | |
|---|---|
| Number of Total Expansion Bays | 60 |
| Number of 3.5" Bays | 60 |
| Misc Ports | |
|---|---|
| Host Interface | 12Gb/s SAS |
