Timeline preview and easy channel, event, alarm configuration
When managing multi channels, XRN-1620SB1/1620B2/820S greatly improves search efficiency by allowing users to preview images and videos by simply hovering mouse cursor on the timeline. Moreover, users can configure event and alarm for all channels within a single page.
Supports live monitoring and bookmarks
With the live monitoring feature, XRN-1620SB1/1620B2/820S allow users to view information by channel including real-time videos, system status, recording status and etc. and also offer easy and detailed monitoring with the digital PTZ control.
Moreover, bookmarks feature makes it possible to save up to 100 major events for the easy and quick event search.
Save cost and install easy NVR with integral PoE
XRN-1620SB1/820S with built-in PoE switches further reduce cost and save installation time by supplying ample power to cameras directly and detecting products automatically upon integration.
- Up to 16 Channels, up to 32MP camera resolution supported
- Maximum 140Mbps network camera recording
- HDM HDMI / VGA monitor output
- User friendly UI / UX
- AI search support when working with Wisenet AI camera
- Dynamic Event support
- New event function of cameras is available without software update
- H.265, H.264, MJPEG codec supported
- Plug & play by 16 PoE ports
- Bookmark management (Up to 100 set)
| Brand | |
|---|---|
| Brand | Hanwha Group |
| Storage | |
|---|---|
| Hard Drive Capacity | 4 TB |
| Screen / Display | |
|---|---|
| Maximum Resolution | 32MP |
| Power & Battery | |
|---|---|
| Power Consumption | 310 W |
| Networking & Connectivity | |
|---|---|
| Ethernet | Yes |
| Connectivity Technology | Wired |
| USB Ports | |
|---|---|
| USB | Yes |
| HDMI Ports | |
|---|---|
| HDMI | Yes |
| Audio Ports | |
|---|---|
| Total Number of Audio Out Por | 1 |
| Camera / Webcam | |
|---|---|
| HD Recording | Yes |
| Recording Formats | 8K |
| Maximum Frame Rate | 200 fps |
| Audio | |
|---|---|
| Total Number of Channels | 16 |
| General Features | |
|---|---|
| System Components | Network Video Recorder |
| Remote Management | Yes |
| Video Formats | Motion JPEG |
| Manufacturer | Hanwha Group |
| Video Ports | |
|---|---|
| Number of VGA Out | 1 |
| Compliance & Certification | |
|---|---|
| NDAA Compliant | Yes |
