5kVA transformer converts UPS 208V input to 120V for powering low-voltage AC components.
Features | 208V to 120V Isolation Transformer Converts High-Voltage Input to Low-Voltage Output
This 5kVA Stepdown Transformer converts your UPS system's 208V high-voltage input to 120V low voltage output. It features 18 NEMA 5-20R outlets (two sets of nine outlets) for connecting equipment with common NEMA 5-15P and NEMA 5-20P plugs. Resettable 20A circuit breakers protect your 120V equipment against overload conditions. The SUTFMR works with select 5kVA to 6kVA SmartOnline® UPS systems.
Versatile Installation Options
You can mount the SUTFMR in 3U of space in an EIA-standard 19-inch rack using the included 4-post rail kit or an optional 2-post rail kit (RK2PC, sold separately). You can also adapt it for tower installation using the included joining bracket and hardware. The three-foot power cord with L6-30P plug connects to a compatible AC outlet.
- Converts 208V AC input into 120V output for powering low voltage equipment
- 18 NEMA 5-20R 120V outlets for connecting components with 5-15P or 5-20P plugs
- Resettable circuit breakers protect mission-critical equipment from hazardous overloads
- 3 ft. power cord with L6-30P input plug connects to compatible AC source
| Brand | |
|---|---|
| Brand | Eaton Corporation |
| Power & Battery | |
|---|---|
| Output Receptacle Detail | 18 x NEMA 5-20R |
| Input Receptacle Type | NEMA L6-30P |
| Output Receptacle Type | NEMA 5-20R |
| Input Voltage | 230 V AC |
| Output Voltage | 120 V |
| Power Rating | 5000 VA |
| Size / Dimensions | |
|---|---|
| Form Factor | Tower/Rack Mountable |
| Rack Height | 3U |
| General Features | |
|---|---|
| Manufacturer | Eaton Corporation |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
