Eaton Metered Input ePDUs
Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3 Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.
Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3 Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.
- PDU improves efficiency, uptime and growth of data centers
- NEMA 5-15R receptacle type to ensure maximum usability and reliable power output
- NEMA L5-30P plug/connector type for reliable, productive connectivity and optimal power output
- 120 V AC input voltage for better reliance and maximum dependability
- 120 V AC output voltage for optimal performance with maximum feasibility
| Brand | |
|---|---|
| Brand | Eaton Corporation |
| Power & Battery | |
|---|---|
| Power Rating (Watt) | 2880 W |
| Circuit Breaker | Yes |
| Receptacle Detail | 12 x NEMA 5-15R |
| Receptacle Type | NEMA 5-15R |
| Plug/Connector Detail | 1 x NEMA L5-30P |
| Plug/Connector Type | NEMA L5-30P |
| Input Voltage | 120 V AC |
| Output Voltage | 120 V AC |
| Input Current | 24 A |
| Ethernet Port | |
|---|---|
| Network (RJ-45) | Yes |
| Size / Dimensions | |
|---|---|
| Mounting Orientation | Horizontal |
| Rack Height | 1U |
| General Features | |
|---|---|
| Protection Type | RFI Filter |
| Manufacturer | Eaton Corporation |
| Cables | |
|---|---|
| Cord Length | 9 ft |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
