Ideal for large venues, the Ultimate Access XL V offers a tab-tensioned, ceiling-recessed screen with complete concealment in sizes up to 22 feet.
The Ultimate Access XL V ceiling-recessed, tab-tensioned electric screen meets the demands of major venues like conference centers and ballrooms. Its case includes a motorized trap door for smooth screen descent and a ceiling closure panel that fully conceals the screen with no visible fasteners. The tab-tensioned design ensures a flat viewing surface for superior image quality, with RF-welded tabs preventing separation and stickiness. A bottom access panel simplifies maintenance, and installing the case early prevents damage and allows the screen to be added later.
- UL Listed.
- Custom sizes available
- White case standard, black available upon request
- Low voltage video interface or other controls can be built into the housing for below ceiling access.
- Junction box and 110V three-position wall switch included for recessed wall mounting.
- Independently motorized ceiling closure panel opens into the case
- Ceiling closure panel can be finished by a contractor to match the ceiling.
- Sliding brackets on top allow for mounting adjustments; inside brackets accommodate different screen sizes.
- Adjustable or removable hoisting brackets included for easy lifting during installation.
- Image area fully framed with black. Standard 12" (30 cm) black drop at top of viewing area.
- Maximum image width up to 22' (671 cm) wide, depending on surface selection. Custom sizes available
- Built-in controls and mounting brackets may increase case dimensions. See Submittal for details.
- Case dimensions are 14-1/16" high x 11" deep (36 cm x 28 cm), includes trim flange.
| Brand | |
|---|---|
| Brand | Draper |
| Screen / Display | |
|---|---|
| Diagonal Image Size | 255" |
| Aspect Ratio | 16:10 |
| Projection Formats | Widescreen |
| Size / Dimensions | |
|---|---|
| Mount Type | Wall Mount |
| Screen Width | 216" |
| Screen Height | 135" |
| Appearance | |
|---|---|
| Screen Folding Mechanism | Electric |
| Screen Fabric | Matt White XT1000VB |
| General Features | |
|---|---|
| Manufacturer | Draper, Inc |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD Gold |
