The Access V projection screen offers a tab-tensioned surface, easy maintenance access, and ceiling-recessed design for complete concealment.
The Access V projection screen delivers a premium, ceiling-recessed solution ideal for commercial environments such as universities, boardrooms, and training rooms. Its concealed design keeps the screen hidden when not in use for a clean, professional appearance. The tab-tensioned surface ensures a perfectly flat viewing area, with RF-welded tabs providing long-term durability. A bottom access panel allows easy maintenance without visible fasteners, and the unit is plenum-rated for use in air-handling spaces.
- Standard white case; black available upon request.
- UL Listed.
- Includes 110V, 3-position switch (standard). Quiet low voltage and 220V motor options available.
- Low voltage, video interface, or other control options can be built into housing for below-ceiling access.
- Quick-connect wiring enables early case installation with screen added later.
- Internal sliding brackets accommodate varying screen sizes.
- Bottom access panel detaches for easy service and maintenance.
- Sliding brackets on top of case allow flexible mounting adjustments.
- Adjustable or removable hoisting brackets included for easier lifting during installation.
- Maximum image width up to 16' (488 cm). Custom sizes available.
- Image area fully framed in black with a standard 12" (30 cm) black drop at the top.
- Built-in controls may increase case length; mounting brackets may add to overall dimensions. See Submittal for details.
- Case dimensions are 7-3/8" high x 8-1/16" deep (19 cm x 20 cm), including trim flange.
| Brand | |
|---|---|
| Brand | Draper |
| Screen / Display | |
|---|---|
| Diagonal Image Size | 94" |
| Aspect Ratio | 16:10 |
| Projection Formats | Widescreen |
| Size / Dimensions | |
|---|---|
| Mount Type | Bracket Mount |
| Screen Width | 80" |
| Screen Height | 50" |
| Appearance | |
|---|---|
| Screen Folding Mechanism | Electric |
| Screen Fabric | Matt White XT1000VB |
| General Features | |
|---|---|
| Manufacturer | Draper, Inc |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
| Environmental Certification | GREENGUARD Gold |
