DRF2666E/32GB is an Unbuffered 4Gx72 memory module, which conforms to JEDEC's DDR4-2666, PC4-2666 standard.
The assembly is Dual-Rank. Each rank is comprised of eighteen 1Gx8 DDR4-2666 SDRAMs. One EEPROM is used for Serial Presence Detect.
Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology.
- RAM Module is the single answer to all your desired and heavy-duty application memory needs
- No matter how heavy and numerous the applications that you are using, 2666 MHz memory speed with unbuffered signal will run them smoothly
- 32 GB of memory can produce approx. 10K MIPS and as a result, your system gets more room to run complex apps.
- 288-pin DDR4-2666/PC4-21333 interface multiplexes 2-bit data from memory cell and I/O buses to minimize processor idle time and enhance your computer's performance
- 1 x 32GB modules for quick access and retrieval of data and information to ensure maximum usability
- 288-pin for faster, dependable performance and better access to data and information
- Server device support for your RAM Module to allow enhanced system performance and reliable memory solution
- DIMM form factor with 288-pin and 32 GB memory size for enhanced performance and speed to allow maximum usability
- Unbuffered signal processing allows higher accuracy and enhanced ram module performance
| Brand | |
|---|---|
| Brand | Dataram Corporation |
| Memory / RAM | |
|---|---|
| Memory Size | 32 GB |
| Memory Technology | DDR4 SDRAM |
| Memory Speed | 2666 MHz |
| Memory Standard | DDR4-2666/PC4-21333 |
| Memory Voltage | 1.20 V |
| Number of Modules | 1 x 32GB |
| Number of Pins | 288-pin |
| Error Checking | ECC |
| Signal Processing | Unbuffered |
| Size / Dimensions | |
|---|---|
| Form Factor | DIMM |
| General Features | |
|---|---|
| Manufacturer | Dataram Corporation |
| Compliance & Certification | |
|---|---|
| Environmentally Friendly | Yes |
Dataram 32GB DDR4 SDRAM Memory Module
