Run Almost Any Application with Multiple PCIe Slots. Unlike most box PCs, the iPC R1is comes with multiple PCIe slots to allow you to tailor the functionality to your needs. The iPC R1is also allows you to use legacy hardware/applications that require a full-size PCI slot.
Full-Size PCIe Card Slots: Many industrial and medical applications require a full-size PCI Express slot to run, particularly high-speed data applications. Newer computers often only have the mini PCI Express slots.
Mini PCIe Slots: With Mini PCIe Slots, your system designers can easily create numerous configurations and expand this custom mini PC's features and signal-handling capabilities.
Because the iPC R1is uses military grade components, it can operate in temperatures from -25°C up to 70°C / (158°F). The device easily adapts to extreme fluctuations in temperature making it the perfect tool for use in factory floors and other industrial working environments.
The iPC R1is is also rated shock and vibration proof for more demanding environments. In addition, fanless cooling technology protects internal components from damage from dust and other particulates in the air. Cybernet's industrial computers boast a less than 2% failure rate and an extremely high mean time between failure (MTBF).
- IEC60068-2-27 certification for shock and vibration
- Dual locking removable drive bays allows you to secure the drive in a safe or other secure areas when not in use
- PCI Express Slots Allow Near Unlimited Functionality
- Support for up to 4 independent full HD output or dual 4k displays
- Terminal Blocks for remote on/off power
- Provides both modern and legacy ports for full connectivity
| Brand | |
|---|---|
| Brand | Cybernet Manufacturing |
| CPU / Processor | |
|---|---|
| Processor Manufacturer | Intel |
| Processor Type | Core i5 |
| Processor Model | i5-6500TE |
| Processor Generation | 6th Gen |
| Processor Speed | 2.30 GHz |
| GPU / Graphics | |
|---|---|
| Graphics Controller Manufacturer | Intel |
| Graphics Controller Model | HD 530 Graphics |
| Graphics Memory Technology | DDR4 SDRAM |
| Graphics Memory Accessibility | Shared |
| Memory / RAM | |
|---|---|
| Standard Memory | 8 GB |
| Memory Technology | DDR4 SDRAM |
| Maximum Memory Supported | 32 GB |
| Storage | |
|---|---|
| Total Solid State Drive Capacity | 128 GB |
| Optical Drive Type | No |
| Networking & Connectivity | |
|---|---|
| Wireless LAN | Yes |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 6 |
| Number of USB 3.0 Ports | 6 |
| DisplayPort | |
|---|---|
| DisplayPort | Yes |
| Number of DisplayPort Outputs | 1 |
| Ethernet Port | |
|---|---|
| Number Of Ethernet Ports | 2 |
| Software & Licensing | |
|---|---|
| Operating System Platform | No |
| Size / Dimensions | |
|---|---|
| Form Factor | Mini PC |
| General Features | |
|---|---|
| Chipset Manufacturer | Intel |
| Manufacturer | Cybernet Manufacturing, Inc |
| Video Ports | |
|---|---|
| DVI | Yes |
| Number of DVI Ports | 2 |
| Compliance & Certification | |
|---|---|
| Energy Efficiency Certificati | ENERGY STAR 6.0 |
| Energy Star | Yes |
| Environmentally Friendly | Yes |
