TOOL-LESS MAGNETIC FRONT PANEL
Quick and easy maintenance with a tool-free magnetic mesh front panel - engineered for airflow and effortless access.
READY FOR HIGH-PERFORMANCE COOLING
Accommodates up to 6 fans and supports 280mm or 360mm radiators to keep your system performing at its peak.
COMPACT SIZE, MAXIMUM COMPATIBILITY
Supports up to 365mm GPUs and 163.5mm CPU coolers - ideal for powerful setups without the bulk.
FRONT I/O USB TYPE-C SUPPORT
Modern connectivity with a built-in USB Type-C port for faster, streamlined data transmission.
ARGB STYLE MEETS PERFORMANCE
Three pre-installed 120mm ARGB fans deliver strong airflow while adding a touch of vibrant lighting to your build.
BREATHABLE PSU SHROUD
Ventilated power supply cover supports both active and passive cooling - offering flexibility and thermal efficiency.
- Mini ITX motherboard builds a perfect symmetry of hardware components required in media server or NAS box
- 3 bays mean more PC components can be added to enhance system's performance
- Freely install the casing anywhere using mini-tower structure that supports up to 6 fan(s) to maintain the casing ambient
| Brand | |
|---|---|
| Brand | Cooler Master Co. |
| GPU / Graphics | |
|---|---|
| Maximum GPU Length | 14.37" |
| Power & Battery | |
|---|---|
| Power Supply Installed | No |
| Maximum PSU Length | 6.30" |
| USB Ports | |
|---|---|
| Total Number of USB Ports | 2 |
| Front USB | Yes |
| USB Port Details | 1 x USB 3.2 Gen 1 Type-A |
| Audio Ports | |
|---|---|
| Headphone/Microphone Combo Po | Yes |
| Total Number of Audio Out Por | 1 |
| Total Number of Audio In Ports | 1 |
| Front Audio In | Yes |
| Front Audio Out | Yes |
| Audio | |
|---|---|
| Microphone | Yes |
| Size / Dimensions | |
|---|---|
| Form Factor | Mini-tower |
| Appearance | |
|---|---|
| Window Panel | Yes |
| Window Panel Location | Left Side |
| General Features | |
|---|---|
| Motherboard Supported | Micro ATX |
| Cooler Type | Fan Cooler |
| Installed Fan Size | 4.72" |
| Installed Fan Size Details | 3 � 120mm |
| Fan Size Supported | 5.51" |
| Maximum CPU Cooler Height | 6.44" |
| Manufacturer | Cooler Master Co., Ltd |
| Number of Fans Supported | 6 |
| Number of Fans Installed | 3 |
| Expansion Slots | |
|---|---|
| Total Number of Expansion Slots | 4 |
| Drive Bays | |
|---|---|
| Number of Total Expansion Bays | 3 |
| Number of Internal 2.5" Bays | 2 |
| Number of Internal 3.5" Bays | 1 |
