| Brand | |
|---|---|
| Brand | Cooler Master |
| Power & Battery | |
|---|---|
| Input Voltage | 120 V AC , 230 V AC |
| Output Voltage | 3.3 V DC , 5 V DC , 5 V SB , 12 V DC , -12 V DC |
| Output Voltage Detail | 3.3 V DC @ 20 A , 5 V DC @ 20 A , 5 V DC @ 3 A , 12 V DC @ 70.8 A , -12 V DC @ 0.3 A |
| Number of SATA Power Connectors | 6 |
| Number of (6+2 pin) PCI Express Power Connectors | 4 |
| Efficiency | 90% |
| Number of (4+4 pin) CPU Power Connectors | 1 |
| Power Factor Correction (PFC) | Active |
| Number of +12V Rails | 1 |
| Output Power | 850 W |
| Size / Dimensions | |
|---|---|
| Form Factor | ATX |
| Fan Diameter | 120 mm |
| Appearance | |
|---|---|
| Modular | Yes |
| General Features | |
|---|---|
| Protection Type | Inrush Current , Over Current , Over Power , Over Temperature , Over Voltage , Short Circuit , Surge , Under Voltage |
| MTBF | 100000 Hour |
| Manufacturer | Cooler Master Co., Ltd |
| Fan Bearing Type | Fluid Bearing |
| Number of Fans | 1 |
| Expansion Slots | |
|---|---|
| PCI Express Connector | Yes |
| Compliance & Certification | |
|---|---|
| Maximum Operating Temperature | 104°F (40°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Energy Efficiency Certification | 80 Plus Gold |
| Energy Efficiency Compliance | Energy-related Products Directive Lot 3 (ErP Lot 3) |
| Specification Compliance | ATX12V v3.1 |
Cooler Master MWE Gold MPX-8503-AFAG 850W Power Supply - ATX - 120 V AC, 230 V AC Input - 3.3 V DC, 5 V DC, 12 V DC, -12 V DC, 5 V SB Output - 850 W - Active PFC - 1 +12V Rails - PCI Express Connector - 1 Fan(s) - 90% Efficiency
